6-16
6-2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
CD-242/CD-266/CD-270 CD-244/CD-267/CD-271
• Abbreviation
AR : Argentine model
AUS : Australian model
CN : Chinese model
CND : Canadian model
EE : East European model
HK : Hong Kong model
JE : Tourist model
KR : Korea model
NE : North European model
RU : Russian model
(Note) Be sure to read “Precautions for Replcement of
CCD Imager” on page 4-8, 4-10 when changing
the CCD imager
A-7074-270-A CD-242 BOARD, COMPLETE
(TRV320/TRV320P)
A-7074-346-A CD-266 BOARD, COMPLETE
(TRV520/TRV520P/TRV525)
A-7074-380-A CD-270 BOARD, COMPLETE (TRV720)
***********************************
(Ref. No.: 20, 000 Series)
(IC001 is not included in this complete board)
< CAPACITOR >
C102 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C105 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C106 1-113-682-11 TANTAL. CHIP 33uF 20% 10V
C108 1-164-360-11 CERAMIC CHIP 0.1uF 16V
< CONNECTOR >
CN101 1-766-346-21 CONNECTOR, FFC/FPC 16P
< IC >
IC101 A-7030-821-A CCD BLOCK ASSY (CCD IMAGER)
< COIL >
L102 1-469-528-91 INDUCTOR 100uH
< TRANSISTOR >
Q101 8-729-117-73 TRANSISTOR 2SC4178-F13F14-T1
< RESISTOR >
R101 1-216-864-11 METAL CHIP 0 5% 1/16W
R102 1-216-864-11 METAL CHIP 0 5% 1/16W
R103 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R105 1-216-857-11 METAL CHIP 1M 5% 1/16W
PPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPP
A-7074-279-A CD-244 BOARD, COMPLETE (TRV320E)
A-7074-376-A CD-267 BOARD, COMPLETE
(TRV420E/TRV520E/TRV620E)
A-7074-370-A CD-271 BOARD, COMPLETE (TRV720E)
***********************************
(Ref. No.: 20, 000 Series)
(IC151 is not included in this complete board)
< CAPACITOR >
C151 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C152 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C155 1-113-682-11 TANTAL. CHIP 33uF 20% 10V
C156 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C157 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C158 1-135-177-21 TANTALUM CHIP 1uF 20% 20V
C159 1-127-820-91 CERAMIC 4.7uF 16V
< CONNECTOR >
CN151 1-766-346-21 CONNECTOR, FFC/FPC 16P
< FERRITE BEAD >
* FB001 1-500-282-11 INDUCTOR CHIP 0uH
< IC >
IC151 A-7031-072-A CCD BLOCK ASSY (CCD IMAGER)
IC152 8-759-561-46 IC AD8014ART-REEL7
< COIL >
L151 1-469-528-91 INDUCTOR 100uH
L152 1-469-528-91 INDUCTOR 100uH
< RESISTOR >
R151 1-216-808-11 METAL CHIP 82 5% 1/16W
R154 1-216-821-11 METAL CHIP 1K 5% 1/16W
R155 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R156 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R157 1-216-864-11 METAL CHIP 0 5% 1/16W
PPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPP
About PD-117/118 board and LCD module,
discriminate LCD type on the machine refer-
ring to page 9, and replace the same type.
