6-2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
– 18 –
DCR-TRV320/TRV320E/TRV320P/TRV420E/TRV520/TRV520E/TRV520P/TRV525
TRV620E/TRV720/TRV720E
PD-133
A-7074-511-A PD-133 BOARD, COMPLETE
(2.5 LCD TYPE SO 61K)
A-7074-512-A PD-133 BOARD, COMPLETE
(2.5 LCD TYPE SO 123K)
***********************
(Ref. No.: 40,000 Series)
< CAPACITOR >
C5501 1-127-688-21 TANTAL. CHIP 10uF 20% 6.3V
C5503 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5504 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5505 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5506 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5507 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5508 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5509 1-107-687-11 TANTAL. CHIP 3.3uF 20% 20V
C5510 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5511 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C5512 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5515 1-164-357-11 CERAMIC CHIP 0.001uF 5% 50V
C5516 1-162-926-11 CERAMIC CHIP 82PF 5% 50V
C5517 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C5518 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C5519 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C5527 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(Note 1)
C5529 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
C5532 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C5533 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C5534 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C5536 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5537 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5538 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C5539 1-107-687-11 TANTAL. CHIP 3.3uF 20% 20V
C5540 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
C5602 1-125-822-11 TANTALUM 10uF 20% 10V
C5603 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C5604 1-164-657-11 CERAMIC CHIP 0.015uF 10% 50V
C5605 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5606 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
0 C5607 1-131-959-91 CERAMIC CHIP 12PF 10% 3KV
C5608 1-125-822-11 TANTALUM 10uF 20% 10V
C5704 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN5501 1-573-364-11 CONNECTOR, FFC/FPC 24P
* CN5502 1-573-984-11 CONNECTOR, BOARD TO BOARD 10P
CN5604 1-764-709-11 CONNECTOR, FFC/FPC (LIF) 10P
CN5701 1-779-893-11 PIN, CONNECTOR (PC BOARD) 8P
CN5702 1-779-064-11 PIN, CONNECTOR (PC BOARD) 12P
CN5703 1-691-344-11 CONNECTOR, FFC/FPC (ZIF) 6P
CN5704 1-778-508-21 PIN, CONNECTOR (PC BOARD) 6P
CN5705 1-764-532-21 CONNECTOR, FFC/FPC (ZIF) 26P
< DIODE >
D5502 8-713-102-80 DIODE 1T369-01-T8A
D5503 8-719-050-42 DIODE RD3.3UM-T1B
D5601 8-719-073-01 DIODE MA111- (K8).S0
D5602 8-719-062-44 DIODE PG1112H-TR
< FERRITE BEAD >
FB5502 1-414-760-21 FERRITE 0uH
< IC >
IC5501 8-759-660-93 IC RB5P004AM1 (Note 1)
IC5501 8-752-100-84 IC CXA3579R-T4 (Note 2)
IC5502 8-752-407-33 IC CXD3512R-T4
IC5601 8-759-564-49 IC TC7W53FU (TE12R)
IC5602 8-759-075-70 IC TA75S393F-TE85R
IC5701 8-759-573-02 IC BU9735K-E2
< COIL >
L5501 1-469-525-91 INDUCTOR 10uH
L5504 1-469-525-91 INDUCTOR 10uH
L5505 1-412-956-21 INDUCTOR 27uH
(2.5 LCD TYPE SO 61K)
L5505 1-412-949-21 INDUCTOR 6.8uH
(2.5 LCD TYPE SO 123K)
L5601 1-419-387-21 INDUCTOR 100uH
L5701 1-414-754-11 INDUCTOR 10uH
About PD-133 board and LCD module, dis-
criminate LCD type on the machine referring
to page 2, and replace the same type.
Note 1: This part is mounted in RB5P004AM1 type.
Note 2: This part is mounted in CXA3579R-T4 type.
To Next Page
