Sony DCR-TRV620E - SE-104;112;114 (STEADYSHOT, AV IN;OUT) PRINTED WIRING BOARD

DCR-TRV320/TRV320E/TRV320P/TRV420E/TRV520/TRV520E/TRV520P/TRV525
TRV620E/TRV720/TRV720E
4-55
4-56
STEADYSHOT, AV IN/OUT
SE-104/112/114
SE-104/112/114 (STEADYSHOT, AV IN/OUT) PRINTED WIRING BOARD
– Ref. No.: SE-104/112/114 board; 20,000 series –
• For Printed Wiring Board.
• There are few cases that the part isn't mounted in this model
is printed on this diagram.
• See page 4-126 for printed parts location.
VTR REC MODEL:DCR-TRV320/TRV320E: E, HK, AUS, CN/
TRV320P/TRV420E: CN/TRV520/TRV520E: E,
HK, AUS, CN, JE/TRV520P/TRV525/TRV620E/
TRV720/TRV720E
PLAYER MODEL: DCR-TRV320E: AEP, UK, EE, NE, RU/
TRV420E: AEP/TRV520E: AEP
S VIDEO
ID-2
AUDIO/
VIDEO
ID-2
LANC/
DIGITAL I/O
DV IN/OUT
SE-104/112/114 BOARD (SIDE A)
DV OUT
VTR REC MODEL
PLAYER MODEL
SE-104: 1-676-772-
SE-112: 1-676-758-
SE-114: 1-676-765-
SE-104/112/114 BOARD (SIDE B)
SE-104:1-676-772-
SE-112:1-676-758-
SE-114: 1-676-765-
