Sony DCR-TRV620E - VF-129

6-41
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R4903 1-218-990-11 SHORT 0
R4904 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4906 1-218-990-11 SHORT 0
R4908 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4910 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4911 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4912 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R4913 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R4914 1-218-990-11 SHORT 0
R4915 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R4916 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R4917 1-218-953-11 RES-CHIP 1K 5% 1/16W
R4918 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R4919 1-218-990-11 SHORT 0
R4920 1-218-965-11 RES-CHIP 10K 5% 1/16W
R4921 1-218-965-11 RES-CHIP 10K 5% 1/16W
R4922 1-218-973-11 RES-CHIP 47K 5% 1/16W
R4923 1-218-973-11 RES-CHIP 47K 5% 1/16W
R4924 1-218-973-11 RES-CHIP 47K 5% 1/16W
R4925 1-218-985-11 RES-CHIP 470K 5% 1/16W
R4926 1-218-985-11 RES-CHIP 470K 5% 1/16W
R4927 1-218-973-11 RES-CHIP 47K 5% 1/16W
R4928 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4929 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4930 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4931 1-218-973-11 RES-CHIP 47K 5% 1/16W
R4932 1-218-973-11 RES-CHIP 47K 5% 1/16W
R4933 1-218-990-11 SHORT 0
R4934 1-218-990-11 SHORT 0
R4935 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4936 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4938 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4939 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4940 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4941 1-218-990-11 SHORT 0
R4942 1-218-990-11 SHORT 0
R4943 1-218-953-11 RES-CHIP 1K 5% 1/16W
R4944 1-218-953-11 RES-CHIP 1K 5% 1/16W
R5701 1-218-990-11 SHORT 0
R5702 1-218-990-11 SHORT 0
R5707 1-218-953-11 RES-CHIP 1K 5% 1/16W
R5708 1-218-953-11 RES-CHIP 1K 5% 1/16W
R5709 1-218-973-11 RES-CHIP 47K 5% 1/16W
R5710 1-218-965-11 RES-CHIP 10K 5% 1/16W
R5711 1-218-941-11 RES-CHIP 100 5% 1/16W
R5712 1-218-941-11 RES-CHIP 100 5% 1/16W
R5714 1-218-973-11 RES-CHIP 47K 5% 1/16W
R5715 1-218-965-11 RES-CHIP 10K 5% 1/16W
R5717 1-218-953-11 RES-CHIP 1K 5% 1/16W
R5718 1-218-967-11 RES-CHIP 15K 5% 1/16W
R5719 1-218-976-11 RES-CHIP 82K 5% 1/16W
R5720 1-218-979-11 RES-CHIP 150K 5% 1/16W
R5721 1-218-973-11 RES-CHIP 47K 5% 1/16W
R5722 1-218-990-11 SHORT 0
R5723 1-218-990-11 SHORT 0
R5724 1-218-985-11 RES-CHIP 470K 5% 1/16W
R5725 1-218-985-11 RES-CHIP 470K 5% 1/16W
R5730 1-218-952-11 RES-CHIP 820 5% 1/16W
R5731 1-218-949-11 RES-CHIP 470 5% 1/16W
R5732 1-218-949-11 RES-CHIP 470 5% 1/16W
R5733 1-218-985-11 RES-CHIP 470K 5% 1/16W
R5735 1-218-990-11 SHORT 0
R5736 1-218-990-11 SHORT 0
R5737 1-218-990-11 SHORT 0
R5738 1-218-990-11 SHORT 0
R5739 1-218-990-11 SHORT 0
R5740 1-218-990-11 SHORT 0
R5741 1-218-990-11 SHORT 0
R5742 1-218-965-11 RES-CHIP 10K 5% 1/16W
R5743 1-218-965-11 RES-CHIP 10K 5% 1/16W
R5744 1-218-973-11 RES-CHIP 47K 5% 1/16W
R5745 1-218-965-11 RES-CHIP 10K 5% 1/16W
R5746 1-218-965-11 RES-CHIP 10K 5% 1/16W
R5747 1-218-973-11 RES-CHIP 47K 5% 1/16W
< TRANSFORMER >
T1301 1-435-252-11 TRANSFORMER, DC-DC CONVERTER
< VIBRATOR >
X1501 1-767-586-21 VIBRATOR, CRYSTAL (27MHZ)
(TRV320/TRV320P/TRV520/TRV520P/TRV525/
TRV720)
X1501 1-767-400-11 VIBRATOR, CRYSTAL (36MHz)
(TRV320E/TRV420E/TRV520E/TRV620E/
TRV720E)
X3301 1-767-399-11 VIBRATOR, CRYSTAL (24.576MHZ)
X4801 1-767-980-21 VIBRATOR, CERAMIC (20MHZ)
X4802 1-760-458-21 VIBRATOR, CRYSTAL (32.768KHZ)
X4901 1-760-655-41 VIBRATOR, CRYSTAL (20MHZ)
PPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPP
A-7073-838-A VF-129 BOARD, COMPLETE
(TRV320/TRV320P/TRV520/TRV520P)
A-7073-855-A VF-129 BOARD, COMPLETE
(TRV320E: E, HK, AUS, CN/TRV420E: CN/
TRV520E: E, HK, AUS, CN, JE)
***********************************
(Ref. No.: 20, 000 Series)
< CAPACITOR >
C901 1-107-854-11 TANTAL. CHIP 68uF 20% 6.3V
C902 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C903 1-135-145-11 TANTALUM CHIP 0.47uF 10% 35V
C904 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C905 1-104-752-11 TANTAL. CHIP 33uF 20% 6.3V
C906 1-162-638-11 CERAMIC CHIP 1uF 16V
C907 1-104-563-11 FILM CHIP 0.1uF 5% 16V
C908 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C909 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
0 C910 1-162-625-11 CERAMIC CHIP 0.0047uF 5% 50V
0 C911 1-164-715-11 CERAMIC CHIP 0.0068uF 5% 50V
C912 1-107-854-11 TANTAL. CHIP 68uF 20% 6.3V
C913 1-135-145-11 TANTALUM CHIP 0.47uF 10% 35V
C914 1-113-984-11 TANTAL. CHIP 1.5uF 20% 35V
C915 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C916 1-164-611-11 CERAMIC CHIP 0.001uF 10% 500V
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
