Sony DCR-TRV620E - VC-235

6-31
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Note: C1504 is mounted on the board with suffix number 13
(23, 33)
SE-104/SE-112/SE-114 VC-235
< SENSOR >
SE201 1-803-042-31 SENSOR, ANGULAR VELOCITY
(PITCH SENSOR)
(TRV320/TRV320P/TRV520/TRV520P/TRV525/
TRV720)
SE201 1-418-252-11 SENSOR, ANGULAR VELOCITY
(PITCH SENSOR)
(TRV320E/TRV420E/TRV520E/TRV620E/
TRV720E)
SE202 1-803-042-41 SENSOR, ANGULAR VELOCITY (YAW SENSOR)
(TRV320/TRV320P/TRV520/TRV520P/TRV525/
TRV720)
SE202 1-418-252-21 SENSOR, ANGULAR VELOCITY (YAW SENSOR)
(TRV320E/TRV420E/TRV520E/TRV620E/
TRV720E)
< VARISTOR >
VDR001 1-801-923-11 VARISTOR, CHIP
PPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPP
A-7094-874-A VC-235 BOARD, COMPLETE (SERVICE)
(TRV320/TRV320P/TRV520/TRV520P)
A-7094-873-A VC-235 BOARD, COMPLETE (SERVICE)
(TRV320E: AEP, UK, EE, NE, RU/TRV420E: AEP/
TRV520E: AEP)
A-7094-878-A VC-235 BOARD, COMPLETE (SERVICE)
(TRV320E: E, HK, AUS, CN/TRV420E: CN/
TRV520E: E, HK, AUS, CN, JE)
A-7094-875-A VC-235 BOARD, COMPLETE (SERVICE)
(TRV525/TRV720)
A-7094-877-A VC-235 BOARD, COMPLETE (SERVICE)
(TRV620E/TRV720E)
***********************************
(Ref. No.: 10, 000 Series)
< CAPACITOR >
C1101 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C1301 1-164-933-11 CERAMIC CHIP 220PF 10% 16V
C1302 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C1303 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C1304 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C1305 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C1306 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C1307 1-164-940-11 CERAMIC CHIP 0.0033uF 10% 16V
C1308 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
C1309 1-164-935-11 CERAMIC CHIP 470PF 10% 16V
C1310 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C1311 1-164-938-11 CERAMIC CHIP 0.0015uF 10% 16V
C1312 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
C1313 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C1314 1-164-935-11 CERAMIC CHIP 470PF 10% 16V
C1315 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C1316 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C1317 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C1318 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C1319 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C1320 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C1321 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C1322 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C1323 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C1326 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C1327 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C1328 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1329 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C1330 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C1331 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C1332 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C1333 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C1334 1-135-157-21 TANTALUM CHIP 10uF 20% 6.3V
C1335 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C1336 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C1337 1-164-506-11 CERAMIC CHIP 4.7uF 16V
C1338 1-164-506-11 CERAMIC CHIP 4.7uF 16V
C1339 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C1340 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C1341 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C1342 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1343 1-135-157-21 TANTALUM CHIP 10uF 20% 6.3V
C1344 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C1345 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C1346 1-135-157-21 TANTALUM CHIP 10uF 20% 6.3V
C1347 1-135-216-11 TANTALUM CHIP 10uF 20% 10V
C1348 1-135-157-21 TANTALUM CHIP 10uF 20% 6.3V
C1350 1-113-985-11 TANTAL. CHIP 10uF 20% 20V
C1351 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
(TRV320/TRV320E: E, HK, AUS, CN/TRV320P/
TRV420E: CN/TRV520/TRV520E: E, HK,
AUS, CN, JE/TRV520P)
C1352 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1353 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1354 1-113-985-11 TANTAL. CHIP 10uF 20% 20V
C1355 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C1356 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C1357 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C1359 1-164-506-11 CERAMIC CHIP 4.7uF 16V
C1501 1-164-858-11 CERAMIC CHIP 22PF 5% 16V
C1502 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C1503 1-164-858-11 CERAMIC CHIP 22PF 5% 16V
C1504 1-115-156-11 CERAMIC CHIP 1uF 10V
(TRV320/TRV320P/TRV520/TRV520P/TRV525/
TRV720) (Note)
C1505 1-115-156-11 CERAMIC CHIP 1uF 10V
C1506 1-107-686-11 TANTAL. CHIP 4.7uF 20% 16V
C1507 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C1508 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C1509 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C1511 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C1512 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C1513 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C1514 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
(TRV320/TRV320P/TRV520/TRV520P/TRV525/
TRV720)
C1514 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
(TRV320E/TRV420E/TRV520E/TRV620E/
TRV720E)
C1515 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C1516 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C1517 1-162-928-11 CERAMIC CHIP 120PF 5% 50V
C1518 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C1519 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
