Sony DCR-TRV620E - CF-69

6-17
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CF-69
A-7074-327-A CF-69 BOARD, COMPLETE
(TRV320/TRV320E: E, HK, AUS, CN/TRV320P)
A-7074-350-A CF-69 BOARD, COMPLETE
(TRV320E: AEP, UK, EE, NE, RU)
**********************************
(Ref. No.: 20, 000 Series)
< BATTERY HOLDER >
BH001 1-550-104-11 HOLDER, BATTERY
< CAPACITOR >
C001 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C009 1-164-346-11 CERAMIC CHIP 1uF 16V
C010 1-164-346-11 CERAMIC CHIP 1uF 16V
(TRV320E: AEP, UK, EE, NE, RU)
C011 1-164-346-11 CERAMIC CHIP 1uF 16V
(TRV320E: AEP, UK, EE, NE, RU)
< CONNECTOR >
CN001 1-785-760-21 CONNECTOR, FFC/FPC (ZIF) 45P
* CN002 1-785-379-01 HOUSING, CONNECTOR 4P
CN003 1-778-506-21 PIN, CONNECTOR (PC BOARD) 2P
CN004 1-779-064-11 PIN, CONNECTOR (PC BOARD) 12P
CN005 1-778-508-21 PIN, CONNECTOR (PC BOARD) 6P
CN006 1-779-334-11 CONNECTOR, FFC/FPC 20P
(TRV320E: AEP, UK, EE, NE, RU)
* CN007 1-778-283-11 CONNECTOR, FFC/FPC 4P
(TRV320/TRV320E: E, HK, AUS, CN/TRV320P)
* CN008 1-580-055-21 PIN, CONNECTOR (SMD) 2P
< DIODE >
D001 8-719-062-16 DIODE 01ZA8.2 (TPL3)
D005 8-719-069-59 DIODE UDZS-TE17-8.2B
D006 8-719-069-59 DIODE UDZS-TE17-8.2B
D008 8-719-027-76 DIODE 1SS357-TPH3
D009 8-719-016-74 DIODE 1SS352-TPH3
< COIL >
L001 1-469-525-91 INDUCTOR 10uH
(TRV320E: AEP, UK, EE, NE, RU)
L002 1-469-525-91 INDUCTOR 10uH
(TRV320E: AEP, UK, EE, NE, RU)
L003 1-469-525-91 INDUCTOR 10uH
(TRV320E: AEP, UK, EE, NE, RU)
< TRANSISTOR >
Q002 8-729-230-63 TRANSISTOR 2SC4116YG-TE85L
Q003 8-729-230-72 TRANSISTOR 2SA1362-YG-EL
< RESISTOR >
R001 1-216-833-91 RES-CHIP 10K 5% 1/16W
R002 1-216-833-91 RES-CHIP 10K 5% 1/16W
R003 1-216-833-91 RES-CHIP 10K 5% 1/16W
R004 1-216-833-91 RES-CHIP 10K 5% 1/16W
R005 1-216-833-91 RES-CHIP 10K 5% 1/16W
R006 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R007 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R008 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R009 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R010 1-216-814-11 METAL CHIP 270 5% 1/16W
R011 1-216-864-11 METAL CHIP 0 5% 1/16W
R012 1-216-845-11 METAL CHIP 100K 5% 1/16W
R013 1-216-803-11 METAL CHIP 33 5% 1/16W
R014 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R015 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R016 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R017 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R019 1-216-816-11 METAL CHIP 390 5% 1/16W
R020 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R021 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R022 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R023 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R024 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R025 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R026 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R027 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R029 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV320E: AEP, UK, EE, NE, RU)
R030 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R031 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R032 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R038 1-216-838-11 METAL CHIP 27K 5% 1/16W
R039 1-216-838-11 METAL CHIP 27K 5% 1/16W
R040 1-216-838-11 METAL CHIP 27K 5% 1/16W
R043 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV320E: AEP, UK, EE, NE, RU)
R044 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV320E: AEP, UK, EE, NE, RU)
R045 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV320E: AEP, UK, EE, NE, RU)
R048 1-216-864-11 METAL CHIP 0 5% 1/16W
R051 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV320E: AEP, UK, EE, NE, RU)
R052 1-216-864-11 METAL CHIP 0 5% 1/16W
R053 1-216-864-11 METAL CHIP 0 5% 1/16W
R054 1-216-814-11 METAL CHIP 270 5% 1/16W
< SWITCH >
S001 1-771-138-61 SWITCH, KEY BOARD (DIGITAL EFFECT)
S002 1-771-138-61 SWITCH, KEY BOARD (+)
S003 1-771-138-61 SWITCH, KEY BOARD (PICTURE EFFECT)
S004 1-771-138-61 SWITCH, KEY BOARD (–)
S005 1-771-138-61 SWITCH, KEY BOARD (DATA CODE)
S006 1-771-025-41 SWITCH, ROTARY (ENCODER)
(SEL/PUSH EXEC)
S007 1-771-138-61 SWITCH, KEY BOARD (MENU)
S008 1-771-138-61 SWITCH, KEY BOARD (INDEX)
S009 1-771-138-61 SWITCH, KEY BOARD (END SEARCH)
S010 1-771-138-61 SWITCH, KEY BOARD (TITLE)
S011 1-771-138-61 SWITCH, KEY BOARD (DELETE)
S012 1-771-138-61 SWITCH, KEY BOARD ( )
S013 1-771-029-21 SWITCH, TACTILE (EXPOSURE)
S014 1-771-138-61 SWITCH, KEY BOARD (PB ZOOM)
S015 1-771-138-61 SWITCH, KEY BOARD (PLAY)
S016 1-771-138-61 SWITCH, KEY BOARD (DISPLAY)
S017 1-771-029-21 SWITCH, TACTILE (PROGRAM AE)
S018 1-771-138-61 SWITCH, KEY BOARD (MEMORY MIX)
S019 1-771-029-21 SWITCH, TACTILE (BACK LIGHT)
S020 1-771-029-31 SWITCH, TACTILE (FADER)
