Sony DCR-TRV620E - PD-117 (2.5 LCD TYPE C 61 K)

6-26
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
PD-117 (2.5 LCD TYPE S 61K)/PD-117 (2.5 LCD TYPE S 123K)
Q5505 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q5506 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q5601 8-729-042-29 TRANSISTOR RN1104F (TPL3)
Q5602 8-729-039-43 TRANSISTOR FP216-TL
Q5603 8-729-042-29 TRANSISTOR RN1104F (TPL3)
Q5604 8-729-042-58 TRANSISTOR RN2102F (TPL3)
< RESISTOR >
R5501 1-216-853-11 METAL CHIP 470K 5% 1/16W
R5503 1-218-895-11 METAL CHIP 100K 0.5% 1/16W
R5504 1-216-845-11 METAL CHIP 100K 5% 1/16W
R5505 1-216-835-11 METAL CHIP 15K 5% 1/16W
R5506 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R5507 1-216-841-11 METAL CHIP 47K 5% 1/16W
R5508 1-216-843-11 METAL CHIP 68K 5% 1/16W
R5509 1-216-837-11 METAL CHIP 22K 5% 1/16W
R5510 1-216-843-11 METAL CHIP 68K 5% 1/16W
R5511 1-216-857-11 METAL CHIP 1M 5% 1/16W
R5512 1-216-845-11 METAL CHIP 100K 5% 1/16W
R5513 1-216-857-11 METAL CHIP 1M 5% 1/16W
R5515 1-216-864-11 METAL CHIP 0 5% 1/16W
R5516 1-216-833-91 RES-CHIP 10K 5% 1/16W
R5519 1-216-864-11 METAL CHIP 0 5% 1/16W
R5520 1-216-864-11 METAL CHIP 0 5% 1/16W
R5521 1-216-864-11 METAL CHIP 0 5% 1/16W
R5523 1-216-809-11 METAL CHIP 100 5% 1/16W
R5524 1-216-809-11 METAL CHIP 100 5% 1/16W
R5525 1-216-809-11 METAL CHIP 100 5% 1/16W
R5551 1-216-841-11 METAL CHIP 47K 5% 1/16W
R5553 1-216-821-11 METAL CHIP 1K 5% 1/16W
(2.5 LCD TYPE S 61K)
R5553 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(2.5 LCD TYPE S 123K)
R5557 1-216-864-11 METAL CHIP 0 5% 1/16W
R5560 1-216-853-11 METAL CHIP 470K 5% 1/16W
R5562 1-216-833-91 RES-CHIP 10K 5% 1/16W
R5563 1-216-841-11 METAL CHIP 47K 5% 1/16W
R5564 1-216-857-11 METAL CHIP 1M 5% 1/16W
R5565 1-216-857-11 METAL CHIP 1M 5% 1/16W
R5569 1-216-848-11 METAL CHIP 180K 5% 1/16W
R5608 1-216-864-11 METAL CHIP 0 5% 1/16W
R5609 1-216-833-91 RES-CHIP 10K 5% 1/16W
R5610 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R5611 1-216-845-11 METAL CHIP 100K 5% 1/16W
R5612 1-216-834-11 METAL CHIP 12K 5% 1/16W
R5613 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R5614 1-216-833-91 RES-CHIP 10K 5% 1/16W
R5616 1-216-810-11 METAL CHIP 120 5% 1/16W
R5617 1-216-837-11 METAL CHIP 22K 5% 1/16W
R5618 1-216-817-11 METAL CHIP 470 5% 1/16W
R5702 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R5704 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R5706 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R5707 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R5708 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R5711 1-216-864-11 METAL CHIP 0 5% 1/16W
R5712 1-216-855-11 METAL CHIP 680K 5% 1/16W
R5714 1-216-864-11 METAL CHIP 0 5% 1/16W
< SWITCH >
S5701 1-692-088-41 SWITCH, TACTILE (LCD BRIGHT +)
S5702 1-692-088-41 SWITCH, TACTILE (LCD BRIGHT –)
S5703 1-692-088-41 SWITCH, TACTILE (VOLUME +)
S5704 1-692-088-41 SWITCH, TACTILE (VOLUME –)
< TRANSFORMER >
0 T5601 1-435-226-11 TRANSFORMER, INVERTER
PPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPP
A-7074-290-A PD-117 BOARD, COMPLETE
(2.5 LCD TYPE C 61K)
***********************************
(Ref. No.: 20, 000 Series)
< CAPACITOR >
C5501 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C5503 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5504 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5505 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5506 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5507 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5508 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5509 1-107-687-11 TANTAL. CHIP 3.3uF 20% 20V
C5510 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5511 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C5512 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5513 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5514 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C5515 1-164-357-11 CERAMIC CHIP 1000PF 5% 50V
C5516 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C5517 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C5518 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C5519 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C5520 1-113-994-11 TANTAL. CHIP 6.8uF 20% 16V
C5521 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C5522 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5523 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5524 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C5527 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5529 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
C5602 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C5603 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C5604 1-164-657-11 CERAMIC CHIP 0.015uF 10% 50V
C5605 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5606 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
0 C5607 1-131-959-91 CERAMIC CHIP 12PF 10% 3KV
C5608 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C5704 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN5501 1-573-364-11 CONNECTOR, FFC/FPC 24P
* CN5502 1-573-984-11 CONNECTOR, BOARD TO BOARD 10P
CN5604 1-764-709-11 CONNECTOR, FFC/FPC (LIF) 10P
CN5701 1-779-893-11 PIN, CONNECTOR (PC BOARD) 8P
CN5702 1-779-064-11 PIN, CONNECTOR (PC BOARD) 12P
CN5703 1-691-344-11 CONNECTOR, FFC/FPC (ZIF) 6P
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
PD-117 (2.5 LCD TYPE C 61K)
