5-16
1-3. CAMERA SYSTEM ADJUSTMENTS
Before perform the camera system adjustments, Check that the
specified values of “27 MHz/36 MHz Origin Oscillation Adjustment”,
“S VIDEO OUT Y level Adjustment” and “S VIDEO OUT C level
Adjustment” of “VIDEO SYSTEM ADJUSTMENT” are satisfied.
1. HALL Adjustment
For detecting the position of the lens iris, adjust the hall AMP gain
and offset.
Subject Not required
Measurement Point Display data of page 1
Measuring Instrument Adjustment remote commander
Adjustment Page F
Adjustment Address 38, 39, 3A
Specified Value 88 to 8C during IRIS OPEN
15 to 19 during IRIS CLOSE
Note: Displayed data of page 1 of the adjustment remote commander.
1 : 00 : XX
Display data
Adjusting method:
1) Select page: 0, address: 01, and set data: 01.
2) Select page: 6, address: 94, and set data: 8A.
3) Select page: 6, address: 95, and set data: 17.
4) Select page: 6, address: 01, set data: 6D, and press the PAUSE
button of the adjustment remote commander. (The HALL
adjustment is performed and the adjustment data is stored in
page: F, address: 38, 39 and 3A)
5) Select page: 6, address: 02, and check that the data is “01”.
6) Select page: 6, address: 01, set data: 00, and press the PAUSE
button.
Checking method:
1) Select page: 0, address: 03, and set data: 03.
2) Select page: 6, address: 01, set data: 01, and press the PAUSE
button.
3) Select page: 1, and check that the display data (Note) during
IRIS OPEN satisfies the specified value.
4) Select page: 6, address: 01, set data: 03, and press the PAUSE
button.
5) Select page: 1, and check that the display data during IRIS
CLOSE satisfies the specified value.
Processing after Completing Adjustments
1) Select page: 6, address: 94, and set data: 00.
2) Select page: 6, address: 95, and set data: 00.
3) Select page: 0, address: 03, and set data: 00.
4) Select page: 0, address: 01, and set data: 00.
5) Select page: 6, address: 01, set data: 00, and press the PAUSE
button.
Address
Initial value
Remark
NTSC PAL
E0 Fixed data-1 (Initialized data)
E1 Fixed data-2
E2 to F2 Fixed data-1 (Initialized data)
F3 Fixed data-2
F4, F5 Fixed data-1 (Initialized data)
F6 Fixed data-2
F7 to FF Fixed data-1 (Initialized data)
1-2-3. MODIFICATION OF B PAGE DATA
1. Modification of B Page Data
When replacing PC-77 board or IC105 of PC-77 board, change the
data of the “Fixed data-2” address shown in the following tables by
manual input.
Mode Memory
Adjusting Page B
Adjusting Address 17 to 1A
Modifying Method:
1) Before changing the data, select page: 0, address: 01, and set
data: 01.
2) New data for changing are not shown in the tables because
they are different in destination. When changing the data, copy
the data built in the same model.
Note :If copy the data built in the different model, the
camcorder may not operate.
3) When changing the data, press the PAUSE button of the
adjustment remote commander each time when setting new
data to write the data in the non-volatile memory.
Processing after Completing Modification of B Page data
1) Select page: 5, address: 0E, set data: 00, and press the PAUSE
button of the adjustment remote commander.
2) Select page: 5, address: 01, set data: FB, and press the PAUSE
button of the adjustment remote commander.
3) Select page: 5, address: 00, set data: 01, and press the PAUSE
button of the adjustment remote commander.
4) Select page: 5, address: 0E, and check that the data is “01”.
5) Select page: 0, address: 01, and set data: 00.
2. B Page Table
Note: Fixed data-2: Modified data. (Refer to “1. Modification of
B Page Data”)
Address Remark
00 to 16 Fixed data-1 (Initialized data)
17 Fixed data-2
18 Fixed data-1 (Initialized data)
19 Fixed data-2
1A
1B to FF Fixed data-1 (Initialized data)
To Next Page
