Sony DCR-TRV620E - PC-77

6-23
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MI-37 PC-77
Note: Varistors are mounted to the location where C117, 119
are printed
R5806 1-218-965-11 RES-CHIP 10K 5% 1/16W
R5807 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R5809 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R5814 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R5815 1-218-953-11 RES-CHIP 1K 5% 1/16W
R5816 1-218-953-11 RES-CHIP 1K 5% 1/16W
R5817 1-218-962-11 RES-CHIP 5.6K 5% 1/16W
R5818 1-218-962-11 RES-CHIP 5.6K 5% 1/16W
R5819 1-218-966-11 RES-CHIP 12K 5% 1/16W
R5820 1-218-969-11 RES-CHIP 22K 5% 1/16W
R5821 1-218-966-11 RES-CHIP 12K 5% 1/16W
R5822 1-218-969-11 RES-CHIP 22K 5% 1/16W
R5823 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R5824 1-218-990-11 SHORT 0
R5825 1-218-990-11 SHORT 0
R5826 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R5827 1-218-968-11 RES-CHIP 18K 5% 1/16W
R5828 1-218-968-11 RES-CHIP 18K 5% 1/16W
R5829 1-218-971-11 RES-CHIP 33K 5% 1/16W
R5830 1-218-977-11 RES-CHIP 100K 5% 1/16W
(TRV320E/TRV420E/TRV520E/TRV620E/
TRV720E)
R5831 1-218-990-11 SHORT 0
(TRV320/TRV320P/TRV520/TRV520P/TRV525/
TRV720)
R5831 1-218-969-11 RES-CHIP 22K 5% 1/16W
(TRV320E/TRV420E/TRV520E/TRV620E/
TRV720E)
R5834 1-218-965-11 RES-CHIP 10K 5% 1/16W
(TRV320/TRV320P/TRV520/TRV520P/TRV525/
TRV720)
R5834 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
(TRV320E/TRV420E/TRV520E/TRV620E/
TRV720E)
R5835 1-218-990-11 SHORT 0
R5836 1-218-990-11 SHORT 0
R5837 1-218-990-11 SHORT 0
R5840 1-218-990-11 SHORT 0
R5841 1-218-990-11 SHORT 0
R5845 1-218-947-11 RES-CHIP 330 5% 1/16W
R5846 1-218-990-11 SHORT 0
(TRV320E/TRV420E/TRV520E/TRV620E/
TRV720E)
R5847 1-218-990-11 SHORT 0
(TRV320E/TRV420E/TRV520E/TRV620E/
TRV720E)
< VARISTOR >
VDR801 1-801-862-11 VARISTOR, CHIP
VDR803 1-801-862-11 VARISTOR, CHIP
PPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPP
A-7074-328-A PC-77 BOARD, COMPLETE
**********************
(Ref. No.: 30, 000 Series)
< CAPACITOR >
C101 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C102 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C104 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C105 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C106 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C108 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C109 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C110 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C111 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C112 1-164-846-11 CERAMIC CHIP 6PF 0.50PF 16V
C113 1-164-847-11 CERAMIC CHIP 7PF 0.50PF 16V
C114 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C115 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C116 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C117 1-801-862-11 VARISTOR, CHIP (Note)
C118 1-164-935-11 CERAMIC CHIP 470PF 10% 16V
C119 1-801-862-11 VARISTOR, CHIP (Note)
C120 1-164-935-11 CERAMIC CHIP 470PF 10% 16V
C121 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C122 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C123 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C125 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C126 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C127 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C128 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C129 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C130 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C131 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C132 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C133 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C134 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C135 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C136 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C137 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C138 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C140 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C141 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C142 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C143 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C144 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C145 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C146 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C147 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C148 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C150 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C151 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C154 1-164-935-11 CERAMIC CHIP 470PF 10% 16V
C155 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C156 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C157 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C158 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C159 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C701 1-164-935-11 CERAMIC CHIP 470PF 10% 16V
C702 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
C703 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C704 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C705 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C706 1-164-878-11 CERAMIC CHIP 150PF 5% 16V
C707 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C708 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
