Sony DCR-TRV620E - Page 229

6-24
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
PC-77
C710 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C711 1-164-935-11 CERAMIC CHIP 470PF 10% 16V
C712 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
C713 1-164-942-11 CERAMIC CHIP 0.0068uF 10% 16V
C714 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C715 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C717 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C718 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C720 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C721 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C722 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C727 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C728 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C801 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C802 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
CN801 1-573-350-11 CONNECTOR, FFC/FPC 10P
CN802 1-774-603-21 CONNECTOR, BOARD TO BOARD 100P
< DIODE >
D101 8-719-016-74 DIODE 1SS352-TPH3
D102 8-719-069-59 DIODE UDZS-TE17-8.2B
D103 8-719-069-59 DIODE UDZS-TE17-8.2B
D104 8-719-069-59 DIODE UDZS-TE17-8.2B
< FERRITE BEAD >
FB101 1-414-813-11 FERRITE 0uH
FB102 1-414-813-11 FERRITE 0uH
FB103 1-414-813-11 FERRITE 0uH
FB104 1-414-813-11 FERRITE 0uH
FB105 1-414-813-11 FERRITE 0uH
FB106 1-414-813-11 FERRITE 0uH
FB107 1-414-813-11 FERRITE 0uH
FB801 1-500-282-11 INDUCTOR CHIP 0uH
< IC >
IC103 8-759-234-20 IC TC7S08F (TE85R)
IC104 8-759-495-15 IC uPD4721GS-GJG-E2
IC105 8-759-668-50 IC HD6417197F77
IC107 8-759-656-23 IC MB81F161622C-80FN
IC108 8-759-657-96 IC MB87J1802PFF-G-BND-ER
IC109 8-759-682-51 IC MBM29LV400BC-90PFTN-S108-ER
IC701 8-759-492-30 IC MB3817PFV-G-BND
IC702 8-759-492-30 IC MB3817PFV-G-BND
< COIL >
L101 1-216-295-91 SHORT 0
L102 1-469-525-91 INDUCTOR 10uH
L701 1-412-056-11 INDUCTOR 4.7uH
L702 1-416-345-11 INDUCTOR 22uH
L703 1-412-056-11 INDUCTOR 4.7uH
L704 1-412-056-11 INDUCTOR 4.7uH
L705 1-416-345-11 INDUCTOR 22uH
L706 1-412-056-11 INDUCTOR 4.7uH
< TRANSISTOR >
Q101 8-729-042-29 TRANSISTOR RN1104F (TPL3)
Q102 8-729-037-61 TRANSISTOR RN2104F (TPL3)
Q103 8-729-042-29 TRANSISTOR RN1104F (TPL3)
Q104 8-729-042-29 TRANSISTOR RN1104F (TPL3)
Q105 8-729-045-75 TRANSISTOR RN1107F (TPL3)
Q106 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
Q701 8-729-046-98 TRANSISTOR CPH6702-TL
Q702 8-729-046-98 TRANSISTOR CPH6702-TL
< RESISTOR >
R102 1-218-973-11 RES-CHIP 47K 5% 1/16W
R103 1-218-990-11 SHORT 0
R104 1-218-953-11 RES-CHIP 1K 5% 1/16W
R105 1-218-990-11 SHORT 0
R106 1-218-977-11 RES-CHIP 100K 5% 1/16W
R107 1-216-864-11 METAL CHIP 0 5% 1/16W
R108 1-218-973-11 RES-CHIP 47K 5% 1/16W
R109 1-218-977-11 RES-CHIP 100K 5% 1/16W
R110 1-218-989-11 RES-CHIP 1M 5% 1/16W
R111 1-218-990-11 SHORT 0
R112 1-218-977-11 RES-CHIP 100K 5% 1/16W
R113 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R114 1-216-864-11 METAL CHIP 0 5% 1/16W
R117 1-216-864-11 METAL CHIP 0 5% 1/16W
R118 1-218-990-11 SHORT 0
R119 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R120 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R121 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R122 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R123 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R124 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R125 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R126 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R128 1-218-977-11 RES-CHIP 100K 5% 1/16W
R129 1-218-953-11 RES-CHIP 1K 5% 1/16W
R130 1-218-973-11 RES-CHIP 47K 5% 1/16W
R131 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R133 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R134 1-218-953-11 RES-CHIP 1K 5% 1/16W
R135 1-218-977-11 RES-CHIP 100K 5% 1/16W
R136 1-218-977-11 RES-CHIP 100K 5% 1/16W
R137 1-218-977-11 RES-CHIP 100K 5% 1/16W
R138 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R139 1-218-977-11 RES-CHIP 100K 5% 1/16W
R140 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R141 1-218-977-11 RES-CHIP 100K 5% 1/16W
R142 1-218-977-11 RES-CHIP 100K 5% 1/16W
R143 1-218-977-11 RES-CHIP 100K 5% 1/16W
R144 1-218-977-11 RES-CHIP 100K 5% 1/16W
R145 1-218-977-11 RES-CHIP 100K 5% 1/16W
R146 1-218-977-11 RES-CHIP 100K 5% 1/16W
R147 1-218-977-11 RES-CHIP 100K 5% 1/16W
R148 1-218-977-11 RES-CHIP 100K 5% 1/16W
R149 1-218-977-11 RES-CHIP 100K 5% 1/16W
R150 1-218-977-11 RES-CHIP 100K 5% 1/16W
R151 1-218-977-11 RES-CHIP 100K 5% 1/16W
R154 1-218-990-11 SHORT 0
R156 1-218-977-11 RES-CHIP 100K 5% 1/16W
R157 1-218-977-11 RES-CHIP 100K 5% 1/16W
R158 1-218-977-11 RES-CHIP 100K 5% 1/16W
R159 1-218-990-11 SHORT 0
R160 1-218-990-11 SHORT 0
R162 1-218-990-11 SHORT 0
R163 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
