Sony DCR-TRV620E - SYSTEM CONTROL SYSTEM ADJUSTMENT

5-45
D
1
(decimal) D
2
(decimal) H
1
(hexadecimal)
(Service model code)
00001 to 65535 D
1
00
65536 to 131071 D
1
– 65536 00
131072 to196607 D
1
– 131072 00
196608 to 262143 D
1
– 196608 00
Page C
Address E8, E9, EA, EB, EC
3-2. SYSTEM CONTROL SYSTEM ADJUSTMENT
1. Initialization of 7, 8, C, D, E, F Page Data
If the 7, 8, C, D, E, F page data is erased due to some reason, perform
“1-2. INITIALIZATION OF 7, 8, C, D, E, F PAGE DATA”, of “5-
1. CAMERA SECTION ADJUSTMENT”
2. Node Unique ID No. Input
Note 1: Perform “2-2. Input of Serial No.” if the data on page C
has been cleared and the node unique ID No. is not found.
2-1. Input of Company ID
Write the company ID to the EEPROM (nonvolatile memory).
Input method:
1) Select page: 0, address: 01, and set data: 01.
2) Enter the following data.
Note 2: Each time the data is set, press the PAUSE button on the
adjusting remote commander.
Address Data
E8 08
E9 00
EA 46
EB 01
EC 01
3) Select page: 0, address: 01, and set data: 00.
2-2. Input of Serial No.
Write the serial No. and model code to the EEPROM (nonvolatile
memory).
In writing the serial No., a decimal number should be converted into
a hexadecimal number.
1) Select page: 0, address: 01, and set data: 01.
2) Read the serial No. from the model name label, and it is assumed
to be D
1.
Example: If serial No. is “77881”,
D1 = 77881
3) From Table 5-3-3, obtain D2 and H1 that correspond to D1.
Example: If D1 = 77881,
D2 = D1 – 65536 = 12345
H1 = 00
Page C
Address ED, EE, EF
Table 5-3-3
4) Enter H1 to address: ED on page: C.
Example: If H1 = 00,
select page: C, address: ED, and set data: 00, then press the
PAUSE button.
5) From Table 5-3-4, obtain the maximum decimal number less
than D
2, and it is assumed to be D3.
Example: If D2 = 12345.
D3 = 12288
6) From Table 5-3-4, obtain a hexadecimal number that corresponds
to D3, and it is assumed to be H3.
Example: If D3 = 12288,
H3 = 3000
7) Caluculate D4 using following equations (decimal caluculation).
(0
D4 225)
D4 = D2 – D3
Example: If D2 = 12345 and D3 = 12288,
D4 = 12345 – 12288 = 57
8) Convert D4 into a hexadecimal number to obtain H4. (See Table
5-4-1 “Hexadecimal - decimal conversion table” in 5-4. Service
Mode)
Example: If D4 = 57,
H4 = 39
9) Enter higher two digits of H3 to address: EE on page: C.
Example: If H3 = 3000,
select page: C, address: EE, and set data: 30, then press the
PAUSE button.
10) Enter H4 to address: EF on page: C.
Example: If H4 = 39,
select page: C, address: EF, and set data: 39, then press the
PAUSE button.
11) Select page: 0, address: 01, and set data: 00.
Ver. 1.1 2001. 01
