Sony DCR-TRV620E - VF-141

6-42
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< CONNECTOR >
* CN901 1-785-379-01 HOUSING, CONNECTOR 4P
* CN902 1-580-057-11 PIN, CONNECTOR (SMD) 4P
< DIODE >
D901 8-719-951-21 DIODE PR1102W-TR (TALLY)
D903 8-719-073-01 DIODE MA111- (K8) .S0
< IC >
IC901 8-759-196-14 IC BA7149F-E2
< COIL >
L901 1-412-031-11 INDUCTOR CHIP 47uH
L902 1-410-387-11 INDUCTOR CHIP 33uH
0 L903 1-411-697-11 COIL, FERRITE (HLC)
< TRANSISTOR >
Q901 8-729-230-63 TRANSISTOR 2SD1819A-QRS-TX
Q902 8-729-106-68 TRANSISTOR 2SD1615-T1GLGK
Q903 8-729-216-31 TRANSISTOR 2SA1163G-TE85L
Q904 8-729-230-63 TRANSISTOR 2SD1819A-QRS-TX
< RESISTOR >
R901 1-216-817-11 METAL CHIP 470 5% 1/16W
R902 1-216-817-11 METAL CHIP 470 5% 1/16W
R903 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R904 1-216-833-91 RES-CHIP 10K 5% 1/16W
R905 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R906 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R907 1-216-845-11 METAL CHIP 100K 5% 1/16W
R908 1-216-852-11 METAL CHIP 390K 5% 1/16W
R909 1-216-833-91 RES-CHIP 10K 5% 1/16W
R910 1-216-835-11 METAL CHIP 15K 5% 1/16W
R911 1-216-160-00 RES-CHIP 27 5% 1/8W
R912 1-216-857-11 METAL CHIP 1M 5% 1/16W
R915 1-218-879-11 METAL CHIP 22K 0.5% 1/16W
(TRV320/TRV320P/TRV520/TRV520P)
R916 1-218-881-11 METAL CHIP 27K 0.5% 1/16W
(TRV320E: E, HK, AUS, CN/TRV420E: CN/
TRV520E: E, HK, AUS, CN, JE)
R917 1-218-893-11 METAL CHIP 82K 0.5% 1/16W
(TRV320E: E, HK, AUS, CN/TRV420E: CN/
TRV520E: E, HK, AUS, CN, JE)
R917 1-218-891-11 METAL CHIP 68K 0.5% 1/16W
(TRV320/TRV320P/TRV520/TRV520P)
R918 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R919 1-216-843-11 METAL CHIP 68K 5% 1/16W
R920 1-216-837-11 METAL CHIP 22K 5% 1/16W
R921 1-216-795-11 RES-CHIP 6.8 5% 1/16W
R922 1-216-850-11 METAL CHIP 270K 5% 1/16W
R923 1-216-857-11 METAL CHIP 1M 5% 1/16W
R924 1-216-862-11 RES-CHIP 2.7M 5% 1/16W
R925 1-216-862-11 RES-CHIP 2.7M 5% 1/16W
R926 1-216-821-11 METAL CHIP 1K 5% 1/16W
R927 1-216-821-11 METAL CHIP 1K 5% 1/16W
R928 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R929 1-216-821-11 METAL CHIP 1K 5% 1/16W
R930 1-216-791-11 METAL CHIP 3.3 5% 1/16W
R931 1-217-671-11 METAL CHIP 1 5% 1/10W
R932 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
< VARIABLE RESISTOR >
RV903 1-238-852-11 RES, ADJ, CERMET 470
RV904 1-238-095-11 RES, ADJ, CERMET 470K
< TRANSFORMER >
0 T901 1-453-124-11 TRANSFORMER ASSY, FLYBACK
< FLAT CABLE >
0 W901 1-540-019-21 SOCKET ASSY, CRT
PPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPP
A-7074-352-A VF-141 BOARD, COMPLETE
(TRV320E: AEP, UK, EE, NE, RU/
TRV420E: AEP/TRV520E: AEP)
A-7074-193-A VF-141 BOARD, COMPLETE
(TRV525/TRV620E/TRV720/TRV720E)
***********************************
(Ref. No.: 20, 000 Series)
< CAPACITOR >
C4501 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C4503 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C4504 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C4507 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4508 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4509 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4510 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C4511 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C4512 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C4513 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C4514 1-107-687-11 TANTAL. CHIP 3.3uF 20% 20V
C4515 1-164-357-11 CERAMIC CHIP 1000PF 5% 50V
C4516 1-162-928-11 CERAMIC CHIP 120PF 5% 50V
C4517 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C4518 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C4519 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C4520 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C4521 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C4523 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C4524 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C4526 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4527 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN4501 1-764-526-11 CONNECTOR, FFC/FPC 18P
CN4502 1-750-630-11 CONNECTOR, FFC/FPC 16P
< DIODE >
D4502 8-713-102-80 DIODE 1T369-01-T8A
D4503 8-719-077-74 DIODE MA2S784008S0
D4504 8-719-077-74 DIODE MA2S784008S0
< FERRITE BEAD >
FB4502 1-500-329-21 INDUCTOR CHIP 0uH
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
VF-129 VF-141
