Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
FB4505 1-500-329-21 INDUCTOR CHIP 0uH
< IC >
IC4501 8-759-591-95 IC RB5P0040M1
(TRV525/TRV620E/TRV720/TRV720E)
IC4501 8-759-660-93 IC RB5P004AM1
(TRV320E: AEP, UK, EE, NE, RU/
TRV420E: AEP/TRV520E: AEP)
IC4502 8-752-400-96 IC CXD3501R-T4
< COIL >
L4501 1-469-525-91 INDUCTOR 10uH
L4504 1-412-949-21 INDUCTOR 6.8uH
< TRANSISTOR >
Q4504 8-729-037-52 TRANSISTOR 2SD2216J-QR (K8) .SO
< RESISTOR >
R4505 1-216-853-11 METAL CHIP 470K 5% 1/16W
R4507 1-218-895-11 METAL CHIP 100K 0.5% 1/16W
R4508 1-216-845-11 METAL CHIP 100K 5% 1/16W
R4513 1-216-835-11 METAL CHIP 15K 5% 1/16W
R4515 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R4516 1-216-841-11 METAL CHIP 47K 5% 1/16W
R4517 1-216-843-11 METAL CHIP 68K 5% 1/16W
R4518 1-216-837-11 METAL CHIP 22K 5% 1/16W
R4520 1-216-843-11 METAL CHIP 68K 5% 1/16W
R4521 1-216-857-11 METAL CHIP 1M 5% 1/16W
R4522 1-216-845-11 METAL CHIP 100K 5% 1/16W
R4524 1-216-844-11 METAL CHIP 82K 5% 1/16W
R4525 1-216-838-11 METAL CHIP 27K 5% 1/16W
R4526 1-216-809-11 METAL CHIP 100 5% 1/16W
R4527 1-216-809-11 METAL CHIP 100 5% 1/16W
R4528 1-216-809-11 METAL CHIP 100 5% 1/16W
R4529 1-216-833-91 RES-CHIP 10K 5% 1/16W
R4530 1-216-845-11 METAL CHIP 100K 5% 1/16W
R4534 1-216-864-11 METAL CHIP 0 5% 1/16W
R4542 1-216-864-11 METAL CHIP 0 5% 1/16W
R4543 1-216-864-11 METAL CHIP 0 5% 1/16W
R4544 1-216-853-11 METAL CHIP 470K 5% 1/16W
PPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPP
MISCELLANEOUS
***************
10 1-676-818-31 FP-156 FLEXIBLE BOARD
11 1-790-334-11 CABLE, FLEXIBLE FLAT (FFC-257S)
59 1-418-801-11 SWITCH BLOCK, CONTROL (MF-10000)
(TRV320/TRV320E/TRV320P)
104 1-418-802-11 SWITCH BLOCK, PANEL REVERSE (PR-10000)
(TRV320/TRV320E/TRV320P)
106 1-960-225-11 HARNESS (DP-83)
(TRV320/TRV320E/TRV320P)
110 A-7094-826-A INDICATION (LCD) BLOCK ASSY (SERVICE)
(TRV320/TRV320E/TRV320P)
157 1-418-801-11 SWITCH BLOCK, CONTROL (MF-10000)
(TRV420E/TRV520/TRV520E/TRV520P/
TRV525/TRV620E)
204 1-418-802-11 SWITCH BLOCK, PANEL REVERSE (PR-10000)
(TRV420E/TRV520/TRV520E/TRV520P/
TRV525/TRV620E)
206 1-960-225-11 HARNESS (DP-83) (TRV420E/TRV520/
TRV520E/TRV520P/TRV525/TRV620E)
210 A-7094-826-A INDICATION (LCD) BLOCK ASSY (SERVICE)
(TRV420E/TRV520/TRV520E/TRV520P/
TRV525/TRV620E)
212 1-418-803-11 SWITCH BLOCK, CONTROL (BV-10000)
(TRV420E/TRV520/TRV520E/TRV520P/
TRV525/TRV620E)
257 1-418-801-11 SWITCH BLOCK, CONTROL (MF-10000)
(TRV720/TRV720E)
262 1-960-227-11 HARNESS (DP-87) (TRV720/TRV720E)
304 1-418-802-11 SWITCH BLOCK, PANEL REVERSE (PR-10000)
(TRV720/TRV720E)
306 1-960-225-11 HARNESS (DP-83) (TRV720/TRV720E)
310 A-7094-826-A INDICATION (LCD) BLOCK ASSY (SERVICE)
(TRV720/TRV720E)
312 1-418-803-11 SWITCH BLOCK, CONTROL (BV-10000)
(TRV720/TRV720E)
359 1-792-454-11 CABLE, FLEXIBLE FLAT (FFC-289) (TRV320/
TRV320E: E, HK, AUS, CN/TRV320P/
TRV420E: CN/TRV520/TRV520E: E,
HK, AUS, CN, JE/TRV520P)
401 1-676-299-11 FP-151 FLEXIBLE BOARD (TRV320E: AEP, UK,
EE, NE, RU/TRV420E: AEP/TRV520E: AEP/
TRV525/TRV620E/TRV720/TRV720E)
456 1-418-800-11 SWITCH BLOCK, CONTROL (SS-10000)
(TRV320/TRV320E: E, HK, AUS, CN/TRV320P/
TRV420E: CN/TRV520/TRV520E: E, HK, AUS,
CN, JE/TRV520P/TRV525/TRV620E/
TRV720/TRV720E)
456 1-418-800-31 SWITCH BLOCK, CONTROL (SS-10000)
(TRV320E: AEP, UK, EE, NE, RU/
TRV420E: AEP/TRV520E: AEP)
465 1-676-823-21 FP-162 FLEXIBLE BOARD
466 1-500-226-31 BEAD, FERRITE
469 1-960-596-11 HARNESS (HT-054)
501 1-793-996-11 CONNECTOR, EXTERNAL
507 1-676-822-11 FP-161 FLEXIBLE BOARD
509 1-758-155-21 FILTER BLOCK, OPTICAL (TRV320E/TRV420E/
TRV520E/TRV620E/TRV720E)
509 1-758-216-21 FILTER BLOCK, OPTICAL (TRV320/TRV320P/
TRV520/TRV520P/TRV525/TRV720)
511 8-848-736-01 DEVICE, LENS LSV-680A
512 1-758-445-11 IRIS IR-680 (including FLEXIBLE BOARD)
551 1-676-819-11 FP-157 FLEXIBLE BOARD
555 1-676-821-11 FP-160 FLEXIBLE BOARD
556 1-500-226-31 BEAD, FERRITE
558 1-676-820-11 FP-159 FLEXIBLE BOARD
565 1-418-799-11 SWITCH BLOCK, CONTROL (FK-10000)
(TRV320/TRV320E: E, HK, AUS, CN/TRV320P/
TRV420E: CN/TRV520/TRV520E: E, HK, AUS,
CN, JE/TRV520P/TRV525/TRV620E/
TRV720/TRV720E)
565 1-418-799-21 SWITCH BLOCK, CONTROL (FK-10000)
(TRV320E: AEP, UK, EE, NE, RU/TRV420E:
AEP/TRV520E: AEP)
760 1-658-213-11 FP-355 FLEXIBLE BOARD
762 1-657-786-13 FP-221 FLEXIBLE BOARD
764 1-658-214-11 FP-356 FLEXIBLE BOARD
803 1-657-785-11 FP-248 FLEXIBLE BOARD
817 1-657-784-11 FP-220 FLEXIBLE BOARD
BT901 1-694-384-11 TERMINAL BOARD, BATTERY
D001 8-719-988-42 DIODE GL453
(Note) Be sure to read “Precuations for Replcement of
CCD Imager” on page 4-8, 4-10 when changing
the CCD imager
VF-141
