Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
MI-37
C5816 1-164-874-11 CERAMIC CHIP 100PF 5% 16V
C5817 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C5818 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
(TRV320E/TRV420E/TRV520E/TRV620E/
TRV720E)
C5819 1-164-874-11 CERAMIC CHIP 100PF 5% 16V
C5820 1-164-874-11 CERAMIC CHIP 100PF 5% 16V
C5821 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
(TRV320E/TRV420E/TRV520E/TRV620E/
TRV720E)
C5822 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5823 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5824 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5825 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5826 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C5827 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C5829 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C5830 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C5832 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C5833 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C5835 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C5836 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C5838 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(TRV320/TRV320P/TRV520/TRV520P/TRV525/
TRV720)
C5839 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C5840 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C5841 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
(TRV320/TRV320P/TRV520/TRV520P/TRV525/
TRV720)
C5841 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(TRV320E/TRV420E/TRV520E/TRV620E/
TRV720E)
C5842 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
(TRV320E/TRV420E/TRV520E/TRV620E/
TRV720E)
C5843 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
(TRV320E/TRV420E/TRV520E/TRV620E/
TRV720E)
C5844 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
(TRV320E/TRV420E/TRV520E/TRV620E/
TRV720E)
< CONNECTOR >
CN5801 1-766-344-21 CONNECTOR, FFC/FPC 14P
* CN5802 1-695-320-21 PIN, CONNECTOR (1.5mm) (SMD) 2P
* CN5803 1-695-320-21 PIN, CONNECTOR (1.5mm) (SMD) 2P
CN5804 1-794-053-21 CONNECTOR, FFC/FPC (LIF) 32P
< DIODE >
D3900 8-719-073-01 DIODE MA111- (K8) .S0
D3901 8-719-074-30 DIODE SML-310LTT86 (TALLY)
D3903 8-719-060-65 DIODE DAC3825 (LASER AV LINK)
D3904 8-719-078-23 DIODE DCR2815 (LASER AV LINK)
D5806 8-719-062-16 DIODE 01ZA8.2 (TPL3)
D5807 8-719-069-59 DIODE UDZS-TE17-8.2B
< FUSE >
0 F3900 1-533-874-11 FUSE, MICRO (200mA/24V)
< IC >
IC3900 8-749-012-83 IC PNA4S13M01S0
IC3901 8-759-498-52 IC LA9511W-TBM
(TRV320/TRV320P/TRV520/TRV520P/TRV525/
TRV720)
IC3901 8-759-566-96 IC AN2920FHQ-EB
(TRV320E/TRV420E/TRV520E/TRV620E/
TRV720E)
IC5801 8-759-638-50 IC AN2901FHQ-EB
(TRV320/TRV320P/TRV520/TRV520P/TRV525/
TRV720)
IC5801 8-759-679-11 IC BH7870AKV-E2
(TRV320E/TRV420E/TRV520E/TRV620E/
TRV720E)
< COIL >
L3900 1-469-525-91 INDUCTOR 10uH
L3901 1-469-525-91 INDUCTOR 10uH
L3902 1-412-948-11 INDUCTOR 5.6uH
L3903 1-412-957-11 INDUCTOR 33uH
L3904 1-412-957-11 INDUCTOR 33uH
L5803 1-412-961-11 INDUCTOR 68uH
< TRANSISTOR >
Q3901 8-729-140-75 TRANSISTOR 2SD999-T1-CLCK
Q3902 8-729-122-63 TRANSISTOR 2SA1226-T1E4
Q3903 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
< RESISTOR >
R3900 1-218-990-11 SHORT 0
R3901 1-218-951-11 RES-CHIP 680 5% 1/16W
R3902 1-216-001-00 METAL CHIP 10 5% 1/10W
R3903 1-218-968-11 RES-CHIP 18K 5% 1/16W
R3904 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R3905 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R3906 1-216-800-11 RES-CHIP 18 5% 1/16W
R3908 1-218-967-11 RES-CHIP 15K 5% 1/16W
R3909 1-218-989-11 RES-CHIP 1M 5% 1/16W
R3910 1-218-990-11 SHORT 0
R3911 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R3912 1-218-947-11 RES-CHIP 330 5% 1/16W
R3913 1-218-953-11 RES-CHIP 1K 5% 1/16W
R3916 1-218-949-11 RES-CHIP 470 5% 1/16W
R3917 1-218-979-11 RES-CHIP 150K 5% 1/16W
R3918 1-218-979-11 RES-CHIP 150K 5% 1/16W
R3919 1-218-950-11 RES-CHIP 560 5% 1/16W
R3920 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R3921 1-218-949-11 RES-CHIP 470 5% 1/16W
R3922 1-218-972-11 RES-CHIP 39K 5% 1/16W
R3923 1-218-949-11 RES-CHIP 470 5% 1/16W
R3924 1-218-949-11 RES-CHIP 470 5% 1/16W
R3936 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R3938 1-218-990-11 SHORT 0
R3939 1-218-990-11 SHORT 0
R5801 1-218-971-11 RES-CHIP 33K 5% 1/16W
R5802 1-218-968-11 RES-CHIP 18K 5% 1/16W
R5803 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R5804 1-216-864-11 METAL CHIP 0 5% 1/16W
R5805 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
