Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
– 19 –
DCR-TRV320/TRV320E/TRV320P/TRV420E/TRV520/TRV520E/TRV520P/TRV525
TRV620E/TRV720/TRV720E
PD-133
< TRANSISTOR >
Q5501 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q5502 8-729-427-74 TRANSISTOR XP4601-TXE
Q5503 8-729-427-74 TRANSISTOR XP4601-TXE
Q5504 8-729-042-26 TRANSISTOR 2SB1462J-QR (K8).SO
Q5505 8-729-041-23 TRANSISTOR NDS356AP
Q5506 8-729-037-74 TRANSISTOR UN9213J- (TX).SO
Q5601 8-729-042-29 TRANSISTOR RN1104F (TPL3)
Q5602 8-729-039-43 TRANSISTOR FP216-TL
Q5603 8-729-042-29 TRANSISTOR RN1104F (TPL3)
Q5604 8-729-042-58 TRANSISTOR RN2102F (TPL3)
< RESISTOR >
R5501 1-216-853-11 METAL CHIP 470K 5% 1/16W
R5503 1-218-895-11 METAL CHIP 100K 0.5% 1/16W
R5504 1-216-845-11 METAL CHIP 100K 5% 1/16W
R5505 1-216-835-11 METAL CHIP 15K 5% 1/16W
(Note 1)
R5506 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R5507 1-216-841-11 METAL CHIP 47K 5% 1/16W
R5508 1-216-843-11 METAL CHIP 68K 5% 1/16W
R5509 1-216-837-11 METAL CHIP 22K 5% 1/16W
R5510 1-216-843-11 METAL CHIP 68K 5% 1/16W
R5511 1-216-857-11 METAL CHIP 1M 5% 1/16W
R5512 1-216-845-11 METAL CHIP 100K 5% 1/16W
R5523 1-216-809-11 METAL CHIP 100 5% 1/16W
R5524 1-216-809-11 METAL CHIP 100 5% 1/16W
R5525 1-216-809-11 METAL CHIP 100 5% 1/16W
R5551 1-216-841-11 METAL CHIP 47K 5% 1/16W
R5553 1-216-837-11 METAL CHIP 22K 5% 1/16W
(2.5 LCD TYPE SO 61K)
R5553 1-216-839-11 METAL CHIP 33K 5% 1/16W
(2.5 LCD TYPE SO 123K)
R5557 1-216-864-11 METAL CHIP 0 5% 1/16W
R5560 1-216-853-11 METAL CHIP 470K 5% 1/16W
R5571 1-216-809-11 METAL CHIP 100 5% 1/16W
R5572 1-216-833-11 METAL CHIP 10K 5% 1/16W
R5573 1-216-833-11 METAL CHIP 10K 5% 1/16W
R5574 1-218-917-11 RES-CHIP 820K 5% 1/16W
R5575 1-216-843-11 METAL CHIP 68K 5% 1/16W
R5576 1-216-857-11 METAL CHIP 1M 5% 1/16W
R5577 1-216-853-11 METAL CHIP 470K 5% 1/16W
R5578 1-216-864-11 METAL CHIP 0 5% 1/16W
R5579 1-216-847-11 METAL CHIP 150K 5% 1/16W
R5585 1-216-864-11 METAL CHIP 0 5% 1/16W
R5586 1-216-864-11 METAL CHIP 0 5% 1/16W
R5587 1-216-864-11 METAL CHIP 0 5% 1/16W
R5588 1-216-864-11 METAL CHIP 0 5% 1/16W
R5589 1-216-864-11 METAL CHIP 0 5% 1/16W
R5591 1-216-845-11 METAL CHIP 100K 5% 1/16W
(Note 1)
R5591 1-216-848-11 METAL CHIP 180K 5% 1/16W
(Note 2)
R5592 1-216-845-11 METAL CHIP 100K 5% 1/16W
(Note 1)
R5592 1-216-839-11 METAL CHIP 33K 5% 1/16W
(Note 2)
R5593 1-216-845-11 METAL CHIP 100K 5% 1/16W
(Note 1)
R5593 1-216-839-11 METAL CHIP 33K 5% 1/16W
(Note 2)
R5594 1-216-845-11 METAL CHIP 100K 5% 1/16W
(Note 1)
R5594 1-216-839-11 METAL CHIP 33K 5% 1/16W
(Note 2)
R5608 1-216-864-11 METAL CHIP 0 5% 1/16W
R5609 1-216-833-11 METAL CHIP 10K 5% 1/16W
R5610 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R5611 1-216-845-11 METAL CHIP 100K 5% 1/16W
R5612 1-216-834-11 METAL CHIP 12K 5% 1/16W
R5613 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R5614 1-216-833-11 METAL CHIP 10K 5% 1/16W
R5616 1-216-810-11 METAL CHIP 120 5% 1/16W
R5617 1-216-837-11 METAL CHIP 22K 5% 1/16W
R5618 1-216-817-11 METAL CHIP 470 5% 1/16W
R5702 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R5704 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R5706 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R5707 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R5708 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R5712 1-216-855-11 METAL CHIP 680K 5% 1/16W
R5714 1-216-864-11 METAL CHIP 0 5% 1/16W
< SWITCH >
S5701 1-692-088-41 SWITCH, TACTILE (LCD BRIGHT +)
S5702 1-692-088-41 SWITCH, TACTILE (LCD BRIGHT -)
S5703 1-692-088-41 SWITCH, TACTILE (VOLUME +)
S5704 1-692-088-41 SWITCH, TACTILE (VOLUME -)
< TRANSFORMER >
0 T5601 1-435-226-11 TRANSFORMER, INVERTER
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
Note 1: This part is mounted in RB5P004AM1 type.
Note 2: This part is mounted in CXA3579R-T4 type.
