5-43
3-1-5. Alignment Tape
The following table lists alignment tapes which are available.
Use the tape specified in the signal column for each adjustment. If
the type of tape to be used for checking operations is not specified,
use whichever type.
Digital8 alignment tape
Name Usage
SW/OL standard (WR5-2D) Switching position adjustment
Audio operation check Audio system adjustment
(WR5-3ND (NTSC),
WR5-3CD (PAL))
System operation check Operation check
(WR5-5ND (NTSC),
WR5-5CD (PAL))
Hi8/standard 8 mm alignment tape
Tape type
ME ......... Particle type metal tape
MP .......... Evaporated type metal tape
Table 5-3-2
Name
Tracking
(WR5-1NP (NTSC), WR5-1CP (PAL))
Video frequency characteristics
(WR5-7NE (NTSC), WR5-7CE (PAL))
Operation check
(WR5-5NSP (NTSC), WR5-5CSP (PAL))
Operation check
(WR5-8NSE (NTSC), WR5-8CSE (PAL))
Operation check
(WR5-4NL (NTSC), WR5-4CL (PAL))
Operation check
(WR5-8NLE (NTSC), WR5-8CLE (PAL)
AFM stereo operation check
WR5-9NS (NTSC), WR5-9CS (PAL)
BPF adjustment
WR5-11NS (NTSC), WR5-11CS (PAL)
Recording
mode
Standard 8 mm
Hi8
Standard 8 mm
Hi8
Standard 8 mm
Hi8
Standard 8 mm
Standard 8 mm
Tape type
MP
ME
MP
ME
MP
ME
MP
MP
Tape
speed
SP
SP (NTSC)
LP (PAL)
SP
SP
LP
LP
SP
SP
Usage
Tape path adjustment, Switching position
adjustment
Frequency characteristics adjustment
Operation check
AFM stereo Operation check
BPF adjustment
