Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
PD-118 (3 LCD TYPE S)/PD-118 (3.5 LCD TYPE S)/PD-118 (4 LCD TYPE S)
C5516 1-162-926-11 CERAMIC CHIP 82PF 5% 50V
(3 LCD TYPE S)
C5517 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C5518 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C5519 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C5520 1-113-994-11 TANTAL. CHIP 6.8uF 20% 16V
C5521 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C5522 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5523 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5524 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C5527 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5528 1-135-177-21 TANTALUM CHIP 1uF 20% 25V
C5529 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
C5530 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5531 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5602 1-113-682-11 TANTAL. CHIP 33uF 20% 10V
C5603 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C5604 1-164-657-11 CERAMIC CHIP 0.015uF 10% 50V
C5605 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5606 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
0 C5607 1-131-959-91 CERAMIC CHIP 12PF 10% 3KV
C5704 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN5501 1-573-364-11 CONNECTOR, FFC/FPC 24P
* CN5502 1-573-984-11 CONNECTOR, BOARD TO BOARD 10P
* CN5604 1-569-352-11 HOUSING, CONNECTOR 10P
CN5701 1-779-893-11 PIN, CONNECTOR (PC BOARD) 8P
CN5702 1-779-064-11 PIN, CONNECTOR (PC BOARD) 12P
* CN5703 1-778-154-21 CONNECTOR, FFC/FPC (ZIF) 6P
CN5704 1-778-508-21 PIN, CONNECTOR (PC BOARD) 6P
CN5705 1-764-532-21 CONNECTOR, FFC/FPC (ZIF) 26P
CN5707 1-691-374-11 CONNECTOR, FFC/FPC 10P
< DIODE >
D5502 8-713-102-80 DIODE 1T369-01-T8A
D5503 8-719-073-01 DIODE MA111- (K8) .S0
0 D5601 8-719-073-01 DIODE MA111- (K8) .S0
D5702 8-719-073-01 DIODE MA111- (K8) .S0
< IC >
IC5501 8-759-660-92 IC RB5P003AM1
IC5502 8-759-660-91 IC LZ9FF424
IC5503 8-759-478-92 IC TC7SET04FU (TE85R)
IC5601 8-759-564-49 IC TC7W53FU (TE12R)
IC5602 8-759-075-70 IC TA75S393F-TE85R
IC5701 8-759-573-02 IC BU9735K-E2
< COIL >
L5501 1-469-525-91 INDUCTOR 10uH
L5502 1-469-525-91 INDUCTOR 10uH
L5503 1-469-525-91 INDUCTOR 10uH
L5504 1-469-525-91 INDUCTOR 10uH
L5505 1-412-949-21 INDUCTOR 6.8uH
L5601 1-419-387-21 INDUCTOR 100uH
< TRANSISTOR >
Q5501 8-729-037-52 TRANSISTOR 2SD2216J-QR (K8) .SO
Q5502 8-729-041-23 TRANSISTOR MGSF1P02LT1
Q5503 8-729-037-53 TRANSISTOR 2SB1462J-QR (K8) .SO
Q5504 8-729-037-53 TRANSISTOR 2SB1462J-QR (K8) .SO
Q5505 8-729-037-52 TRANSISTOR 2SD2216J-QR (K8) .SO
Q5506 8-729-037-52 TRANSISTOR 2SD2216J-QR (K8) .SO
Q5601 8-729-037-74 TRANSISTOR UN9213J- (K8) .SO
Q5602 8-729-039-43 TRANSISTOR FP216-TL
Q5603 8-729-037-74 TRANSISTOR UN9213J- (K8) .SO
Q5604 8-729-042-58 TRANSISTOR UN9111J- (K8) .SO
< RESISTOR >
R5501 1-216-853-11 METAL CHIP 470K 5% 1/16W
R5503 1-218-895-11 METAL CHIP 100K 0.5% 1/16W
R5504 1-216-845-11 METAL CHIP 100K 5% 1/16W
R5505 1-216-835-11 METAL CHIP 15K 5% 1/16W
R5506 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R5507 1-216-841-11 METAL CHIP 47K 5% 1/16W
R5508 1-216-843-11 METAL CHIP 68K 5% 1/16W
R5509 1-216-837-11 METAL CHIP 22K 5% 1/16W
R5510 1-216-843-11 METAL CHIP 68K 5% 1/16W
R5511 1-216-857-11 METAL CHIP 1M 5% 1/16W
R5512 1-216-845-11 METAL CHIP 100K 5% 1/16W
R5513 1-216-857-11 METAL CHIP 1M 5% 1/16W
R5515 1-216-864-11 METAL CHIP 0 5% 1/16W
R5516 1-216-833-91 RES-CHIP 10K 5% 1/16W
R5519 1-216-864-11 METAL CHIP 0 5% 1/16W
R5520 1-216-864-11 METAL CHIP 0 5% 1/16W
R5521 1-216-864-11 METAL CHIP 0 5% 1/16W
R5523 1-216-809-11 METAL CHIP 100 5% 1/16W
R5524 1-216-809-11 METAL CHIP 100 5% 1/16W
R5525 1-216-809-11 METAL CHIP 100 5% 1/16W
R5551 1-216-841-11 METAL CHIP 47K 5% 1/16W
R5553 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
(4 LCD TYPE S)
R5553 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
(3.5 LCD TYPE S)
R5553 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(3 LCD TYPE S)
R5557 1-216-864-11 METAL CHIP 0 5% 1/16W
R5560 1-216-853-11 METAL CHIP 470K 5% 1/16W
R5562 1-216-833-91 RES-CHIP 10K 5% 1/16W
R5563 1-216-841-11 METAL CHIP 47K 5% 1/16W
R5564 1-216-857-11 METAL CHIP 1M 5% 1/16W
R5565 1-216-857-11 METAL CHIP 1M 5% 1/16W
R5569 1-216-848-11 METAL CHIP 180K 5% 1/16W
R5608 1-216-864-11 METAL CHIP 0 5% 1/16W
R5609 1-216-833-91 RES-CHIP 10K 5% 1/16W
R5610 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R5611 1-216-845-11 METAL CHIP 100K 5% 1/16W
R5612 1-216-834-11 METAL CHIP 12K 5% 1/16W
R5613 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R5614 1-216-836-11 METAL CHIP 18K 5% 1/16W
R5616 1-216-810-11 METAL CHIP 120 5% 1/16W
R5617 1-216-837-11 METAL CHIP 22K 5% 1/16W
R5618 1-216-817-11 METAL CHIP 470 5% 1/16W
R5702 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
To Next Page
