6-36
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
L3601 1-469-525-91 INDUCTOR 10uH
L3602 1-469-525-91 INDUCTOR 10uH
L3701 1-469-525-91 INDUCTOR 10uH
L3705 1-469-525-91 INDUCTOR 10uH
L5701 1-414-754-11 INDUCTOR 10uH
< TRANSISTOR >
Q1101 8-729-042-29 TRANSISTOR RN1104F (TPL3)
Q1102 8-729-042-29 TRANSISTOR RN1104F (TPL3)
Q1103 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
Q1104 8-729-042-29 TRANSISTOR RN1104F (TPL3)
(TRV320/TRV320E/TRV320P/TRV420E/
TRV520/TRV520E/TRV520P)
Q1301 8-729-043-60 TRANSISTOR CPH6102-TL
Q1302 8-729-046-98 TRANSISTOR CPH6702-TL
Q1303 8-729-046-98 TRANSISTOR CPH6702-TL
Q1304 8-729-046-98 TRANSISTOR CPH6702-TL
Q1305 8-729-046-98 TRANSISTOR CPH6702-TL
Q1306 8-729-046-98 TRANSISTOR CPH6702-TL
Q1307 8-729-044-58 TRANSISTOR SI2304DS-T1
Q1308 8-729-044-58 TRANSISTOR SI2304DS-T1
Q1309 8-729-046-98 TRANSISTOR CPH6702-TL
Q1310 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q1311 8-729-017-61 TRANSISTOR 2SB1581-T1
Q1312 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
Q1313 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q1314 8-729-042-29 TRANSISTOR RN1104F (TPL3)
Q1315 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
Q1316 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q1317 8-729-037-74 TRANSISTOR UN9213J- (K8) .SO
(TRV320/TRV320E: E, HK, AUS, CN/TRV320P/
TRV420E: CN/TRV520/TRV520E: E, HK,
AUS, CN, JE/TRV520P)
Q1318 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
Q1319 8-729-041-23 TRANSISTOR MGSF1P02LT1
(TRV320/TRV320E: E, HK, AUS, CN/TRV320P/
TRV420E: CN/TRV520/TRV520E: E, HK,
AUS, CN, JE/TRV520P)
Q1320 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q1321 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q1322 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
Q1323 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
Q1324 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q1325 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q1326 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
Q1551 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q1552 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
Q1553 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
Q1554 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q2204 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
Q2206 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q3102 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
Q3103 8-729-042-29 TRANSISTOR RN1104F (TPL3)
Q3104 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q3105 8-729-042-29 TRANSISTOR RN1104F (TPL3)
Q3106 8-729-042-29 TRANSISTOR RN1104F (TPL3)
Q3107 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q3108 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
Q3109 8-729-042-58 TRANSISTOR RN2102F (TPL3)
Q3110 8-729-042-58 TRANSISTOR RN2102F (TPL3)
Q3111 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
Q3112 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q3113 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q3114 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q3115 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q3116 8-729-047-19 TRANSISTOR 2SA1965-S-TL
Q3201 8-729-042-29 TRANSISTOR RN1104F (TPL3)
Q3301 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
(TRV525/TRV620E/TRV720/TRV720E)
Q3302 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
Q3303 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
(TRV525/TRV620E/TRV720/TRV720E)
Q3304 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
Q3305 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
Q3306 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
Q3307 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
Q3308 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
Q3602 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
Q3603 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q3604 8-729-807-86 TRANSISTOR 2SB1295-UL5/6-TB
Q3605 8-729-042-29 TRANSISTOR RN1104F (TPL3)
Q3606 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
Q3701 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q4401 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q4402 8-729-042-29 TRANSISTOR RN1104F (TPL3)
Q4801 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q4802 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q4803 8-729-042-29 TRANSISTOR RN1104F (TPL3)
Q4804 8-729-041-43 TRANSISTOR HN1L02FU (TE85R)
Q4805 8-729-042-29 TRANSISTOR RN1104F (TPL3)
Q4806 8-729-042-29 TRANSISTOR RN1104F (TPL3)
Q4807 8-729-042-29 TRANSISTOR RN1104F (TPL3)
Q4808 8-729-037-61 TRANSISTOR RN2104F (TPL3)
Q4809 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
Q4810 8-729-037-52 TRANSISTOR 2SD2216J-QR (K8) .SO
Q4811 8-729-042-57 TRANSISTOR UN9110J- (K8) .SO
Q4812 8-729-037-71 TRANSISTOR UN9210J- (K8) .SO
Q4901 8-729-045-71 TRANSISTOR RN1102F (TPL3)
Q5701 8-729-045-78 TRANSISTOR RN1110F (TPL3)
Q5703 8-729-045-78 TRANSISTOR RN1110F (TPL3)
Q5704 8-729-045-78 TRANSISTOR RN1110F (TPL3)
Q5706 8-729-045-78 TRANSISTOR RN1110F (TPL3)
Q5708 8-729-037-63 TRANSISTOR RN2111F (TPL3)
Q5714 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
Q5715 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR (TPL3)
< RESISTOR >
R1101 1-218-990-11 SHORT 0
R1124 1-218-990-11 SHORT 0
R1127 1-218-974-11 RES-CHIP 56K 5% 1/16W
(TRV320/TRV320P/TRV520/TRV520P)
R1127 1-218-965-11 RES-CHIP 10K 5% 1/16W
(TRV320E: E, HK, AUS, CN/TRV420E: CN/
TRV520E: E, HK, AUS, CN, JE)
R1127 1-218-969-11 RES-CHIP 22K 5% 1/16W
(TRV320E: AEP, UK, EE, NE, RU/
TRV420E: AEP/TRV520E: AEP)
R1127 1-218-973-11 RES-CHIP 47K 5% 1/16W
(TRV620E/TRV720E)
R1127 1-218-977-11 RES-CHIP 100K 5% 1/16W
(TRV525/TRV720)
R1128 1-218-975-11 RES-CHIP 68K 5% 1/16W
(TRV320/TRV320P/TRV520/TRV520P)
VC-235
