SECTION 7
ELECTRICAL PARTS LIST
A-2167-159-A AMP BOARD, COMPLETE (See Note)
********************
< CONNECTOR >
CN6002 1-779-992-11 PIN, CONNECTOR (PWB) 8P
CN6003 1-770-469-21 PIN, CONNECTOR (PC BOARD) 2P
CN6005 1-794-509-11 PIN, CONNECTOR (PC BOARD) (3P)
CN7001 1-816-296-21 PIN, CONNECTOR (PC BOARD) 9P
CN7002 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN7003 1-785-728-21 PIN (PC BOARD), CONNECTOR 7P
CN7004 1-774-729-21 PIN, CONNECTOR (PC BOARD) 10P
CN7005 1-764-250-21 PIN, CONNECTOR (PC BOARD) 4P
CN7006 1-793-331-31 CONNECTOR, FFC/FPC (LIF) 20P
CN7007 1-766-652-61 CONNECTOR, FFC/FPC 16P
< DIODE >
D7002 6-502-961-01 DIODE DA2J10100L
D7003 6-503-040-01 DIODE DZ2J300M0L
< FUSE >
0 F6002 1-523-144-31 FUSE (5 A/32 V)
0 F6003 1-523-144-31 FUSE (5 A/32 V)
0 F6004 1-523-144-31 FUSE (5 A/32 V)
0 F6005 1-523-144-31 FUSE (5 A/32 V)
0 F6006 1-523-144-31 FUSE (5 A/32 V)
0 F6007 1-523-144-31 FUSE (5 A/32 V)
0 F7001 1-576-415-31 FUSE (2 A/32 V)
0 F7002 1-523-144-31 FUSE (5 A/32 V)
0 F7003 1-523-144-31 FUSE (5 A/32 V)
0 F7004 1-523-144-31 FUSE (5 A/32 V)
0 F7005 1-523-144-31 FUSE (5 A/32 V)
0 F7006 1-523-144-31 FUSE (5 A/32 V)
0 F7007 1-523-144-31 FUSE (5 A/32 V)
0 F7008 1-576-415-31 FUSE (5 A/32 V)
0 F7009 1-576-415-31 FUSE (5 A/32 V)
< FERRITE BEAD >
FB7001 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB7002 1-400-179-21 INDUCTOR, EMI FERRITE (1608)
FB7003 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB7014 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB7034 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
< IC >
IC6004 6-723-251-01 IC TAS5624ADDVR-S (See Note)
IC6005 6-723-251-01 IC TAS5624ADDVR-S (See Note)
IC6006 6-723-526-01 IC TAS5548DCAR
IC6007 6-723-251-01 IC TAS5624ADDVR-S (See Note)
IC6009 6-721-116-01 IC BU33UC3WG-TR
IC7002 6-721-694-01 IC RT7272BGSP
IC7003 6-721-874-01 IC RT7295CGJ6F
IC7004 6-723-251-01 IC TAS5624ADDVR-S (See Note)
IC7005 6-723-251-01 IC TAS5624ADDVR-S (See Note)
IC7006 6-723-526-01 IC TAS5548DCAR
IC7007 6-723-251-01 IC TAS5624ADDVR-S (See Note)
IC7009 6-721-116-01 IC BU33UC3WG-TR
IC7011 6-721-694-01 IC RT7272BGSP
< JUMPER RESISTOR >
JC6004 1-216-864-91 SHORT CHIP 0
JC6005 1-216-864-91 SHORT CHIP 0
JC6007 1-216-864-91 SHORT CHIP 0
JC6008 1-216-864-91 SHORT CHIP 0
JC6016 1-216-864-91 SHORT CHIP 0
JC6017 1-216-864-91 SHORT CHIP 0
JC7004 1-216-864-91 SHORT CHIP 0
JC7005 1-216-864-91 SHORT CHIP 0
JC7007 1-216-864-91 SHORT CHIP 0
JC7008 1-216-864-91 SHORT CHIP 0
JC7016 1-216-864-91 SHORT CHIP 0
JC7017 1-216-864-91 SHORT CHIP 0
< TRANSISTOR >
Q6002 8-729-013-22 TRANSISTOR HN1A01FU
Q6005 8-729-013-22 TRANSISTOR HN1A01FU
Q6007 8-729-013-22 TRANSISTOR HN1A01FU
Q6008 8-729-013-22 TRANSISTOR HN1A01FU
Q6009 8-729-013-22 TRANSISTOR HN1A01FU
Q6010 8-729-013-22 TRANSISTOR HN1A01FU
Q7001 6-552-892-01 TRANSISTOR LSCR523UBFS8TL
Q7002 8-729-013-22 TRANSISTOR HN1A01FU
Q7003 6-552-446-01 TRANSISTOR DRC5144T0L
Q7004 6-553-711-01 FET NTJS4151PT1G
Q7005 8-729-013-22 TRANSISTOR HN1A01FU
Q7006 6-552-936-01 TRANSISTOR LTC014EUBFS8TL
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
Due to standardization, replacements in
the parts list may be different from the
parts speci ed in the diagrams or the com-
ponents used on the set.
-XX and -X mean standardized parts, so
they may have some difference from the
original one.
Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal- lm resistor.
METAL OXIDE: Metal oxide- lm resistor.
F: non ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
The components identi ed by mark 9 con-
tain con dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identi és par la marque
9 contiennent des informations con den-
tielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé
et / ou réparé.
The components identi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number speci ed.
Les composants identi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spéci é.
Among mounted electrical parts on each
boards, only parts that are described in
the electrical parts list can be replaced for
repair.
The parts that are not described in the
electrical parts list cannot be replaced with
single for repairing.
Note: When the complete AMP board or IC6004, IC6005, IC6007, IC7004,
IC7005 or IC7007 on the AMP board is replaced, refer to “SPREADING
OF COMPOUND” on page 8.
