Sony HT-ST5000 Service Manual

HT-ST5000
27
2-18. AUDIO SELECTOR BOARD
connector
(CN8006)
3DVWLQJSRVLWLRQRIWKHJDVNHW6/
3DVWLQJSRVLWLRQRIWKHJDVFNHW6/
1 screw
(BV/ring)
1 screw
(BV/ring)
2 gasket
(SL)
right side
bottom side
bottom side
gasket
(SL)
gasket (SL)
bracket (shield MB-B)
gasket
(SL)
top side
1 two screws
(BV/ring)
1 screw
(BV/ring)
4 gasket
(SL)
4 gasket
(SL)
guide line DSP board
rear side
1RWHDERXWLQVWDOOLQJWKHEUDFNHWVKLHOG0%RUWKHEUDFNHWVKLHOG0%%
)LJ)!
E
E
E
hole
hole
rib
rib
rib
rib
3 bracket (shield MB-B)
(See Fig. F)
Note 2:
When installing the bracket
(shield MB-B), align the two
ribs and two holes.
3 bracket (shield MB)
(See Fig. F)
Note 1:
When installing the bracket
(shield MB), align the two
ribs and two holes.
8 AUDIO SELECTOR board
6 two screws
(BVTP3 u 8)
5 FFC 30P
(CN2002)
6 screw
(BVTP3 u 8)
7 connector
(CN2001)
terminal side
chassis block
86&1'
$(38.
bottom side
bracket
(shield MB)
or
bracket
(shield MB-B)
The gasket (SL) is
correctly installed
under the bracket
(shield MB) or
bracket (shield MB-B).
The gasket (SL) is
pinched and deformed
under the bracket
(shield MB) or bracket
(shield MB-B).
2.
NG
