Sony HT-ST5000 Service Manual

HT-ST5000
16
2-5. BAR WIRED BOARD
Note 1:
Lay a soft piece of cloth under the unit
to avoid damaging the grille assy.
right side
bottom side
top side
3 two screws
(BVTP3 u 8)
1
sheet
(
plug
)
2 step screw
(B3 u 6)
4
Lift up the
panel (back R)
block
in the direction of the arrow.
6
panel (back R) block
5 CHUKEI-WIRE board cable
connector (CN9900)
right side
guide line
sheet (plug)
sheet (plug)
sheet (plug)
rear
cover
block
rear
cover
block
rear
cover
block
sheet (plug)
panel
(back R)
block
front side
3DVWLQJSRVLWLRQRIWKHVKHHWSOXJ
top side
–5HDUYLHZ–
OK
NG
NG
7 screw
(BVTP3 u 6)
7 screw
(BVTP3 u 6)
hole
boss
boss
hole
8 bracket wired
Note 2:
When installing the bracket wired,
align the two bosses and two holes.
9 BAR WIRED board
Note 3:
When installing the
BAR WIRED board,
align the boss and hole.
–5LJKWYLHZ–
–5LJKWYLHZ–
–5LJKWYLHZ–
hole
guide line
guide line
guide line
guide line
panel (back R)
rear
cover
block

Sony HT-ST5000 Specifications

General

Audio decoders	Dolby Atmos, Dolby Digital, Dolby Dual Mono
RMS rated power	- W
Audio output channels	7.1.2 channels
Soundbar speaker RMS power	90 W
Subwoofer included	Yes
Subwoofer connectivity	Wireless
Receiver included	-
Product color	Black
Bluetooth profiles	A2DP, AVRCP
HDMI in	3
HDMI ports quantity	4
Number of HDMI outputs	1
Connectivity technology	Wired & Wireless
Power consumption (standby)	0.5 W
Power consumption (typical)	7 W

Weight and Dimensions

Depth	145 mm
Width	1180 mm
Height	80 mm
Soundbar weight	8200 g
Subwoofer depth	426 mm
Subwoofer width	248 mm
Subwoofer height	403 mm
Subwoofer weight	14100 g
