5-6. BLOCK DIAGRAM - AMP Section -
: AUDIO
SIGNAL PATH
DIGITAL POWER AMP
IC6004
14 INPUT_C
6 INPUT_B
5 INPUT_A
15 INPUT_D
16 FAULT
4 RESET
STREAM PROCESSOR,
SAMPLE RATE CONVERTER
IC6006
37VALID
24 SDIN1
25 SDIN2
26 SDIN2-1 (SDIN3)
22 LRCLK
23 SCLK
D5
D7
D6
LRCK
BCK
D5, D6, D7
LRCK, BCK
DRIVER_SD
DRIVER_SD
DRIVER_SD
>013B
43PWM_P_3
42PWM_M_3
45PWM_P_4
44PWM_M_4
47PWM_P_7
46PWM_M_7
49PWM_P_8
48PWM_M_8
54PWM_P_5
53PWM_M_5
56PWM_P_6
55PWM_M_6
32OUT_C
28OUT_D
27OUT_D
40OUT_A
39OUT_A
35OUT_B
L.P.F.
L.P.F.
L.P.F.
L.P.F.
DIGITAL POWER AMP
IC6005
14 INPUT_C
6 INPUT_B
5 INPUT_A
15 INPUT_D
16 FAULT
4 RESET
OVF
OVF
18 CLIP
OVF
18 CLIP
17 OTW
32OUT_C
28OUT_D
27OUT_D
40OUT_A
39OUT_A
35OUT_B
L.P.F.
L.P.F.
L.P.F.
L.P.F.
DIGITAL POWER AMP
IC6007
14 INPUT_C
6 INPUT_B
5 INPUT_A
15 INPUT_D
16 FAULT
4 RESET
17 OTW
32OUT_C
28OUT_D
27OUT_D
40OUT_A
39OUT_A
35OUT_B
L.P.F.
L.P.F.
L.P.F.
L.P.F.
SP7
SATELLITE
(SURROUND L-CH)
SP8
SATELLITE
(SURROUND BACK L-CH)
SP9
SATELLITE
(SURROUND BACK R-CH)
SP10
SATELLITE
(SURROUND R-CH)
SP12
SPEAKER
(TOP R-CH)
SP11
SPEAKER
(TOP L-CH)
OVER LOAD
DETECT
Q6005
OVER LOAD
DETECT
Q6002
OVER LOAD
DETECT
Q6008
OVER LOAD
DETECT
Q6007
OVER LOAD
DETECT
Q6010
OVER LOAD
DETECT
Q6009
DIGITAL POWER AMP
IC7004
14 INPUT_C
6 INPUT_B
5 INPUT_A
15 INPUT_D
16 FAULT
4 RESET
STREAM PROCESSOR,
SAMPLE RATE CONVERTER
IC7006
37VALID
24 SDIN1
25 SDIN2
26 SDIN2-1 (SDIN3)
27 SDIN2-2 (SDIN4)
20 SDA
21 SCL
22 LRCLK
23 SCLK
19 MUTE
18 PDN
16 RESET
D4
D1
D3
D2
LRCK
BCK
DRIVER_SD, OVF
DRIVER_SD
OVF
D1, D2, D3, D4,
LRCK, BCK
DRIVER_SD
DRIVER_SD
DRIVER_SD
SYSTEM CONTROLLER
IC3002 (6/7)
>012B
20 SDA
21 SCL
19 MUTE
18 PDN
16 RESET
TAS5538_SDA
TAS5538_SCL
TAS5538_XMUTE
TAS5538_XPDN
TAS5538_XRST
DRIVER_SD/POWER_DET
DRIVER_TH_WARN
DC_DET
43PWM_P_3
42PWM_M_3
45PWM_P_4
44PWM_M_4
47PWM_P_7
46PWM_M_7
49PWM_P_8
48PWM_M_8
54PWM_P_5
53PWM_M_5
56PWM_P_6
55PWM_M_6
32OUT_C
28OUT_D
27OUT_D
40OUT_A
39OUT_A
35OUT_B
L.P.F.
L.P.F.
L.P.F.
L.P.F.
DIGITAL POWER AMP
IC7005
14 INPUT_C
6 INPUT_B
5 INPUT_A
15 INPUT_D
16 FAULT
4 RESET
17 OTW
32OUT_C
28OUT_D
27OUT_D
40OUT_A
39OUT_A
35OUT_B
L.P.F.
L.P.F.
L.P.F.
L.P.F.
17 OTW
17 OTW
DIGITAL POWER AMP
IC7007
14 INPUT_C
6 INPUT_B
5 INPUT_A
15 INPUT_D
16 FAULT
4 RESET
17 OTW
32OUT_C
28OUT_D
27OUT_D
40OUT_A
39OUT_A
35OUT_B
L.P.F.
L.P.F.
L.P.F.
L.P.F.
SP1
WOOFER
(FRONT L-CH)
SP2
TWEETER
(FRONT L-CH)
SP3
WOOFER
(FRONT R-CH)
SP4
TWEETER
(FRONT R-CH)
SP6
TWEETER
(CENTER)
SP5
WOOFER
(CENTER)
OVER LOAD
DETECT
Q7005
OVER LOAD
DETECT
Q7002
OVER LOAD
DETECT
Q7008
OVER LOAD
DETECT
Q7007
OVER LOAD
DETECT
Q7010
OVER LOAD
DETECT
Q7009
DC DETECT
Q7001
162
154
168
146
147
153
152
148
OVF
18 CLIP
OVF
18 CLIP
OVF
18 CLIP
18 CLIP
XTALO12
XTALI
11
X7001
12.288MHz
XTALO
12
XTALI
11
X6001
12.288MHz
(Page 76)
(Page 76)
