Sony HT-ST5000 Service Manual

HT-ST5000
99
2 4
VOUT
1
VOUT
VFB
3
LCON
5
GND
8
VDD
7
VDD
6
CE
VREF
CURRENT LIMIT
THERMAL SHUTDOWN
REVERCE
DETECTOR
– USB-CHUKEI Board –
IC1802 RP115L331D-E2
12V CLAMP
CIRCUIT
4.0V
REGULATOR
STARTER
578
2
1 3
ZT
FB
CS
4
GND
VH N.C.
6
VCC OUT
SOFT
START
LEADING EDGE
BLANKING
ZT BLANKING
OUT
TRIGGER
DETECT
LOGIC
MAX FREQUENCY
CONTROL
CURRENT SENSE
PRE
DRIVER
S
R
Q
+

+

+


+

0.50V
DCDC
COMP.
2.6V/2.8V
VREF
VREF
VREF
STOP
TIMER
DELAY
TIMER
+

0.50V
OSC
TIME
OUT
1SHOT
+

13.5V/
8.2V
27.5V
13.0V/
8.7V
VCC
UVLO
VCC
OVP
+

100mV
/200mV
+

+

5.0V
BURST COMP.
OLP
ZT
COMP.
ZT OVP
COMP.
ZT ACSNS
COMP.
– BAR POWER Board –
IC901 BM1Q002FJ-E2

Sony HT-ST5000 Specifications

General

Audio decoders	Dolby Atmos, Dolby Digital, Dolby Dual Mono
RMS rated power	- W
Audio output channels	7.1.2 channels
Soundbar speaker RMS power	90 W
Subwoofer included	Yes
Subwoofer connectivity	Wireless
Receiver included	-
Product color	Black
Bluetooth profiles	A2DP, AVRCP
HDMI in	3
HDMI ports quantity	4
Number of HDMI outputs	1
Connectivity technology	Wired & Wireless
Power consumption (standby)	0.5 W
Power consumption (typical)	7 W

Weight and Dimensions

Depth	145 mm
Width	1180 mm
Height	80 mm
Soundbar weight	8200 g
Subwoofer depth	426 mm
Subwoofer width	248 mm
Subwoofer height	403 mm
Subwoofer weight	14100 g
