– 2 –
• Floppy disk that can be used by the MVC-FD83/FD88
• Size : 3.5-inch
• Type : 2 HD
• Capacity : 1.44 MB
• Format : MS-DOS format
(512 bytes × 18 sector)
(FD can be formatted by the MVC-FD83/FD88)
1. Check the area of your repair for unsoldered or poorly-sol-
dered connections. Check the entire board surface for solder
splashes and bridges.
2. Check the interboard wiring to ensure that no wires are
“pinched” or contact high-wattage resistors.
3. Look for unauthorized replacement parts, particularly transis-
tors, that were installed during a previous repair. Point them
out to the customer and recommend their replacement.
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer.
4. Look for parts which, though functioning, show obvious signs
of deterioration. Point them out to the customer and recom-
mend their replacement.
5. Check the B+ voltage to see it is at the values specified.
6. Flexible Circuit Board Repairing
• Keep the temperature of the soldering iron around 270 ˚C
during repairing.
• Do not touch the soldering iron on the same conductor of
the circuit board (within 3 times).
• Be careful not to apply force on the conductor when sol-
dering or unsoldering.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE !
SUR LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE
DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ
DE FONCTIONNEMENT. NE REMPLACER CES COM-
POSANTS QUE PAR DES PIÈCES SONY DONT LES
NUMÉROS SONT DONNÉS DANS CE MANUEL OU
DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK ! OR DOTTED
LINE WITH MARK ! ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-
LISHED BY SONY.
Model MVC-FD83 MVC-FD88 MVC-FD83K MVC-FD88K
Destination
US, CND, AEP, UK, E, US, CND, AEP, UK, E, J J
AUS, HK, CH, KR AUS, HK, CH, KR, JE
Image device 1/3-inch CCD 1/3.6-inch CCD 1/3-inch CCD 1/3.6-inch CCD
Lens 3 × 8 × 3 × 8 ×
Digital zoom 6 × 16 × 6 × 16 ×
CD board CD-229 CD-228 CD-229 CD-228
FU board FU-135 FU-137 FU-135 FU-137
PK board PK-47 PK-48 PK-47 PK-48
RL board RL-54 RL-56 RL-54 RL-56
Table for differences of function
Note: MVC-FD83K/FD88K are the same as MVC-FD83/FD88
except accessories and packing materials.
MVC-FD83K : MVC-FD83 + Accessory kit
MVC-FD88K : MVC-FD88 + Accessory kit
• Abbreviation
AUS : Australian model
CH : Chinese model
CND: Canadian model
J : Japanese model
HK : Hong Kong model
KR : Korea model
JE : Tourist model
