5-10
3. B Page Table
Note 1: Fixed data-1: Initialized Data. (Refer to “1. Initializing
the B, E, F Page Data”)
Fixed data-2: Modified Data. (Refer to “2. Modification
of B, E, F Page Data”)
Address Initial Remark
Value
00 to 87 Fixed data-1 (Initialized data)
88 0F CCD defect compensation
89 FF
8A 0F
8B FF
8C 0F
8D FF
8E 0F
8F FF
90 0F
91 FF
92 0F
93 FF
94 0F
95 FF
96 0F
97 FF
98 0F
99 FF
9A 0F
9B FF
9C 0F
9D FF
9E 0F
9F FF
A0 0F
A1 FF
A2 0F
A3 FF
A4 0F
A5 FF
A6 0F
A7 FF
A8 0F
A9 FF
AA 0F
AB FF
AC 0F
AD FF
AE 0F
AF FF
B0 to FF Fixed data-1 (Initialized data)
Table. 5-1-4
4. E Page Table
Note 1: Fixed data-1: Initialized Data. (Refer to “1. Initializing
the B, E, F Page Data”)
Fixed data-2: Modified Data. (Refer to “2. Modification
of B, E, F Page Data”)
Address Initial Remark
Value
00 to FF Fixed data-1 (Initialized data)
Table. 5-1-5
1-2-2. Initialization of B, E, F Page Data
1. Initializing the B, E, F Page Data
Note: If the B, E, F page data has been initialized, “Modification
of B, E, F Page Data” and following adjustments need to
be performed again.
1) Modification of B, E, F page data
2) Video system adjustments
3) Camera system adjustments
Adjustment Page B
Adjustment Address 00 to FF
Adjustment Page E
Adjustment Address 00 to FF
Adjustment Page F
Adjustment Address 10 to FF
Initializing Method:
1) Select page: 0, address: 01, and set data: 01.
2) Select page: 6, address: 00, and set data: 2D.
3) Select page: 6, address: 01, set data: 2D and press the PAUSE
button of the adjusting remote commander.
4) Select page: 6, address: 02, and check that the data changes to
“01”.
5) Perform “Modification of B, E, F Page Data”
2. Modification of B, E, F Page Data
If the B, E, F Page data has been initialized, change the data of the
“Fixed data-2” address shown in the following tables by manual
input.
Modifying Method:
1) Before changing the data, select page: 0, address: 01, and set
data: 01.
2) New data for changing are not shown in the tables because
they are different in destination. When changing the data, copy
the data built in the same model.
Note: If copy the data built in the different model, the
camrecorder may not operate.
3) When changing the data, press the PAUSE button of the ad-
justing remote commander each time when setting new data
to write the data in the non-volatile memory.
4) Check that the data of adjustment addresses is the initial value.
If not, change the data to the initial value.
Processing after Completing Modification of B, E, F Page
data
1) Select page: 2, address: 00, and set data: 29.
2) Select page: 2, address: 01, and set data: 29, and press the
PAUSE button of the adjusting remote commander.
To Next Page
