5-18
9. Auto White Balance Standard Data Input
Adjust the white balance standard data at 3200K.
Mode STILL
Subject Clear chart
(Color reproduction adjustment
frame)
Adjustment Page F
Adjustment Address 3A to 3D
Note 1: Check that the data of page: 6, address: 02 is “00”.
If not, turn the power of unit OFF/ON.
Adjusting method:
1) Select page: 0, address: 01, and set data: 01.
2) Select page: E, address: 52, after noting down the data, set
data: 1B, and press the PAUSE button of the adjusting remote
commander.
3) Select page: 6, address: 10, and set data: 58.
4) Select page: B, address: 41, set data: 30, and press the PAUSE
button of the adjusting remote commander.
5) Select page: 6, address: 01, set data: 11, and press the PAUSE
button of the adjusting remote commander.
6) Select page: 6, address: 01, set data: 0B, and press the PAUSE
button of the adjusting remote commander.
(The auto white balance standard data input is performed and
the standard data is stored in page: F, addresses: 3A to 3D)
7) Select page: 6, address: 02, and check that the data is “01”.
Processing after Completing Adjustments:
1) Select page: 6, address: 01, set data: 00, and press the PAUSE
button of the adjusting remote commander.
2) Select page: 6, address: 10, and set data: 00.
3) Select page: B, address: 41, set data: 00, and press the PAUSE
button of the adjusting remote commander.
4) Select page: E, address: 52, set data noted down at step 2) and
press the PAUSE button of the adjusting remote commander.
5) Select page: 0, address: 01, and set data: 00.
6) Perform “Auto White Balance Adjustment”. (FD83)
Perform “Auto White Balance ND Filter Compensation”.
(FD88)
10.White Balance ND Filter Compensation (FD88)
Adjust to compensate the white balance at ND filter ON.
Mode STILL
Subject Clear chart
(Color reproduction adjustment
frame)
Adjustment Page F
Adjustment Address 4F, 50
Note 1: Check that the data of page: 6, address: 02 is “00”.
If not, turn the power of unit OFF/ON.
Adjusting method:
1) Select page: 0, address: 01, and set data: 01.
2) Select page: E, address: 52, after noting down the data, set
data: 1B, and press the PAUSE button of the adjusting remote
commander.
3) Select page: 6, address: 10, and set data: 58.
4) Select page: B, address: 41, set data: 30, and press the PAUSE
button of the adjusting remote commander.
5) Select page: 6, address: 1C, and set data: 03.
6) Wait for 1 second.
7) Select page: 6, address: 01, set data: 11, and press the PAUSE
button of the adjusting remote commander.
8) Select page: 6, address: 01, set data: 09, and press the PAUSE
button of the adjusting remote commander.
(The white balance ND filter compensation is performed and
the compensation data is stored in page: F, addresses: 4F and
50)
9) Select page: 6, address: 02, and check that the data is “01”.
Processing after Completing Adjustments:
1) Select page: 6, address: 01, set data: 00, and press the PAUSE
button of the adjusting remote commander.
2) Select page: 6, address: 1C, and set data: 00.
3) Select page: 6, address: 10, and set data: 00.
4) Select page: B, address: 41, set data: 00, and press the PAUSE
button of the adjusting remote commander.
5) Select page: E, address: 52, set data noted down at step 2) and
press the PAUSE button of the adjusting remote commander.
6) Select page: 0, address: 01, and set data: 00.
7) Perform “Auto White Balance Adjustment”.
To Next Page
