Sony MVC-FD83 - Adjusting Items When Replacing Boards and EEPROM

5-3
Replaced parts
Board
replacement
Adjustment section Adjustment
Initialization of Initialization of D page data rr r
B, D, E, F page data Initialization of B, E, F page data rr r
Video Video sync level adj. rr r
Video burst level adj. rr r
Camera HALL adj. rr r
Flange back adj. rr r
F No. standard data input rr r
Mechanical shutter adjustment (FD88) rr
Light level adj. rr r
Auto white balance standard data input rr r
White balance ND filter compensation (FD88) rr
Auto white balance adj. rr r
Color reproduction adj. rr r
Color reproduction adj. (ND filter ON) (FD88) rr
Strobe white balance adj. rr r
CCD defect compensation rr r
LCD LCD initial data input rrrr
VCO adj. (NTSC) rrrr
VCO adj. (PAL) rrrr
D range adj. rrrr
Bright adj. rrrr
Contrast adj. rrrr
Color adj. rrrr
V-COM level adj. rrrr
V-COM adj. rrrr
White balance adj. rrrr
System control Battery down adj. rrrr
Alignment check (FDD unit) r
FC-70 board (COMPLETE) (FD83) FC-70 board (COMPLETE) (FD88) PK-47/48 board (COMPLETE) FC-70 board IC305 EEP R FC-70 board IC402 EEP ROM
2. Adjusting Items when Replacing Boards and EEPROM
When replacing board and EEPROM, adjust the items indicated by r in the following table.
Table. 5-1-2
