6-5
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
6-2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
Les composants identifiés par une
marque ! sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
CD-228 CD-229 FC-70
A-7074-007-A CD-228 BOARD, COMPLETE (FD88)
**********************
(Ref.No.: 2,000 Series)
(IC201 is not included in this complete board)
< CAPACITOR >
C201 1-113-985-11 TANTAL. CHIP 10uF 20% 20V
C203 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C204 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C205 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C206 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
< CONNECTOR >
CN201 1-766-348-21 CONNECTOR, FFC/FPC 18P
< IC >
IC201 A-7030-999-A CCD BLOCK ASSY (CCD IMAGER)
< COIL >
L201 1-414-757-11 INDUCTOR 100uH
< TRANSISTOR >
Q201 8-729-117-73 TRANSISTOR 2SC4178-F13F14-T1
Q202 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
< RESISTOR >
R201 1-216-864-11 METAL CHIP 0 5% 1/16W
R202 1-216-864-11 METAL CHIP 0 5% 1/16W
R203 1-216-864-11 METAL CHIP 0 5% 1/16W
R204 1-216-857-11 METAL CHIP 1M 5% 1/16W
R205 1-216-864-11 METAL CHIP 0 5% 1/16W
R206 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R207 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
A-7074-013-A CD-229 BOARD, COMPLETE (FD83)
**********************
(Ref.No.: 2,000 Series)
(IC101 is not included in this complete board)
< CAPACITOR >
C101 1-113-985-11 TANTAL. CHIP 10uF 20% 20V
C103 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C104 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C105 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C106 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
< CONNECTOR >
CN101 1-766-348-21 CONNECTOR, FFC/FPC 18P
< IC >
IC101 A-7031-017-A CCD BLOCK ASSY (CCD IMAGER)
< COIL >
L101 1-414-757-11 INDUCTOR 100uH
< TRANSISTOR >
Q101 8-729-117-73 TRANSISTOR 2SC4178-F13F14-T1
< RESISTOR >
R101 1-216-864-11 METAL CHIP 0 5% 1/16W
R102 1-216-864-11 METAL CHIP 0 5% 1/16W
R103 1-216-864-11 METAL CHIP 0 5% 1/16W
R104 1-216-857-11 METAL CHIP 1M 5% 1/16W
R105 1-216-864-11 METAL CHIP 0 5% 1/16W
R106 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
A-7074-042-A FC-70 BOARD, COMPLETE (SERVICE) (FD88)
A-7074-043-A FC-70 BOARD, COMPLETE (SERVICE) (FD83)
*********************
(Ref.No.: 1,000 Series)
< BATTERY >
* BT301 1-528-900-11 BATTERY, LITHIUM SECONDARY
< CAPACITOR >
C001 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C002 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C003 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
• Abbreviation
AUS : Australian model CH : Chinese model
CND : Canadian model J : Japanese model
HK : Hong Kong model KR : Korea model
JE : Tourist model
Be sure to read “Note on the CCD imager replacement”
on page 4-6, 4-8 when changing the CCD Imager.
To Next Page
