5-25
19.Strobe Light Level and White Balance Check
Check the light level regulation and the white balance when the
strobe light flashed.
Mode STILL
Subject A plate which reflection rate is 18%
(1.0 m from the front of lens)
Measurement Point Displayed data of page: 1
Measuring Instrument Adjusting remote commander
Specified Value Y level data: 68 to A0 (Note 3)
R-Y level data: FA to FF or 00 to
06 (Note 4)
B-Y level data: FA to FF or 00 to
06 (Note 4)
Note 1: Perform this adjustment in the dark room or use a dark
box.
Note 2: Any light other than the strobe light should not light up
the plate.
Note 3: The right two digits of the page: 1displayed data of the
adjusting remote commander
1:00:XX
→ Y level data
Note 4: The right four digits of the page: 1displayed data of the
adjusting remote commander
1:XX:XX
→ B-Y level data
→ R-Y level data
Adjusting method:
1) Select page: 0, address: 01, and set data: 01.
2) Select page: E, address: 52, after noting down the data, set
data: 1B, and press the PAUSE button of the adjusting remote
commander.
3) Select page: 6, address: 10, and set data: 58.
4) Select page: 6, address: 90, and set data: 00.
5) Select page: 6, address: 91 and set data: 00.
6) Select page: 6, address: 92, and set data: 00.
7) Select page: 6, address: 93, and set data: 60.
8) Select page: 6, address: 2C, and set data: 01.
9) Select page: 6, address: 01, set data: 79, and press the PAUSE
button of the adjusting remote commander.
10) Select page: 6, address: 01, set data: 67, and press the PAUSE
button of the adjusting remote commander.
11) Check the flashing of strobe light.
12) Select page: 0, address: 03, and set data: 01.
13) Select page: 1, and check the Y level (Note 3) data satisfies the
specified value.
14) Select page: 0, address: 03, and set data: 02.
15) Select page: 1, and check the R-Y, B-Y level data (Note 4)
satisfies the specified value.
Processing after Completing Adjustments:
1) Select page: 0, address: 03, and set data: 00.
2) Select page: 6, address: 01, set data: 00, and press the PAUSE
button of the adjusting remote commander.
3) Select page: 6, address: 2C, and set data: 00.
4) Select page: 6, address: 93, and set data: 00.
5) Select page: 6, address: 10, and set data: 00.
6) Select page: E, address: 52, set data noted down at step 2) and
press the PAUSE button of the adjusting remote commander.
7) Select page: 0, address: 01, and set data: 00.
20.CCD Black Defect Compensation
Mode STILL
Subject Clear chart
(25 cm from the front of lens)
Measurement Point Displayed data of page: 1,
address: 55
Measuring Instrument Adjusting remote commander
Adjustment Page B
Adjustment Address 88 to AF
Specified Value 0A or less
Note 1: Check that there are no dust, no dirt and reflection of the
clear chart.
Note 2: Any subject other than the clear chart should be in the
screen.
Adjusting method:
1) Select page: 0, address: 01, and set data: 01.
2) Select page: E, addresses: 88 to AF, and input data: FF to each
address.
Note: Press the PAUSE button of the adjusting remote com-
mander each time to set data.
3) Select page: E, address: 52, after noting down the data, set
data: 50, and press the PAUSE button of the adjusting remote
commander.
4) Select page: F, address: AF, set data: B3, and press the PAUSE
button of adjusting remote commander.
5) Select page: 6, address: 2C, and set data: 01.
6) Select page: 6, address: 90, and set data: 00.
7) Select page: 6, address: 91, and set data: 04.
8) Select page: 6, address: 92, and set data: 00.
9) Select page: 6, address: 93, and set data: 00.
10) Select page: 6, address: 01, set data: 79, and press the PAUSE
button of adjusting remote commander.
11) Select page: 6, address: 30, and set data: 07.
12) Wait for 2 second.
13) Select page: 6, address: 01, set data: 8D, and press the PAUSE
button of adjusting remote commander.
(The CCD defect compensation is performed and the compen-
sation data is stored in page: B, address: 88 to AF)
14) Select page: 6, address: 02, and check that the data is “01”.
15) Select page: 6, address: 55, and check that the black defection
data is satisfies the specified value.
Processing after Completing Adjustments:
1) Select page: 6, address: 01, set data: 00, and press the PAUSE
button of adjusting remote commander.
2) Select page: 6, address: 91, and set data: 00.
3) Select page: 6, address: 2C, and set data: 00.
4) Select page: 6, address: 30, and set data: 00.
5) Select page: E, address: 52, set data noted down at step 3) and
press the PAUSE button of the adjusting remote commander.
6) Select page: 0, address: 01, and set data: 00.
To Next Page
