12.Color Reproduction Adjustment
Adjust the color separation matrix coefficient so that proper color
reproduction is produced.
Mode STILL
Subject Color bar chart
(Color reproduction adjustment
frame)
Adjustment Page F
Adjustment Address 41 to 48, 5C to 5F
Note 1: Perform “Auto White Balance Reference Data Input” be-
fore this adjustment.
Note 2: Check that the data of page: 6, address: 02 is “00”.
If not, turn the power of unit OFF/ON.
Adjusting method:
1) Select page: 0, address: 01, and set data: 01.
2) Select page: E, address: 52, after noting down the data, set
data: 1B, and press the PAUSE button of the adjusting remote
commander.
3) Select page: 6, address: 10, and set data: 59.
4) Select page: B, address: 41, set data: 30, and press the PAUSE
button of the adjusting remote commander.
5) Select page: 6, address: 01, set data: AB and press the PAUSE
button of the adjusting remote commander.
6) Select page: 6, address: 01, set data: A9, and press the PAUSE
button of the adjusting remote commander.
(The color reproduction adjustment is performed and the ad-
justment data is stored in page: F, addresses: 41 to 48, 5C to
5F)
7) Select page: 6, address: 02, and check that the data is “01”.
Processing after Completing Adjustments:
1) Select page: 6, address: 01, set data: 00, and press the PAUSE
button of the adjusting remote commander.
2) Select page: 6, address: 10, and set data: 00.
3) Select page: B, address: 41, set data: 00, and press the PAUSE
button of the adjusting remote commander.
4) Select page: E, address: 52, set data noted down at step 2) and
press the PAUSE button of the adjusting remote commander.
5) Select page: 0, address: 01, and set data: 00.
13.Color Reproduction Adjustment (ND Filter ON)
(FD88)
Adjust the color separation matrix coefficient so that proper color
reproduction is produced.
Mode STILL
Subject Color bar chart
(Color reproduction adjustment
frame)
Adjustment Page F
Adjustment Address 51 to 58, 60 to 63
Note 1: Perform “Auto White Balance Reference Data Input” and
“White Balance ND Filter Compensation” before this ad-
justment.
Note 2: Check that the data of page: 6, address: 02 is “00”.
If not, turn the power of unit OFF/ON.
Adjusting method:
1) Select page: 0, address: 01, and set data: 01.
2) Select page: E, address: 52, after noting down the data, set
data: 1B, and press the PAUSE button of the adjusting remote
commander.
3) Select page: 6, address: 10, and set data: 59.
4) Select page: B, address: 41, set data: 30, and press the PAUSE
button of the adjusting remote commander.
5) Select page: 6, address: 1C, set data: 03, and press the PAUSE
button of the adjusting remote commander.
6) Wait for 1 second.
7) Select page: 6, address: 01, set data: A3, and press the PAUSE
button of the adjusting remote commander.
8) Select page: 6, address: 01, set data: A1, and press the PAUSE
button of the adjusting remote commander.
(The color reproduction adjustment (ND filter ON) is per-
formed and the adjustment data is stored in page: F, addresses:
51 to 58, 60 to 63)
9) Select page: 6, address: 02, and check that the data is “01”.
Processing after Completing Adjustments:
1) Select page: 6, address: 01, set data: 00, and press the PAUSE
button of the adjusting remote commander.
2) Select page: 6, address: 1C, set data: 00, and press the PAUSE
button of the adjusting remote commander.
3) Select page: 6, address: 10, and set data: 00.
4) Select page: B, address: 41, set data: 00, and press the PAUSE
button of the adjusting remote commander.
5) Select page: E, address: 52, set data noted down at step 2) and
press the PAUSE button of the adjusting remote commander.
6) Select page: 0, address: 01, and set data: 00.
