Version 5.2 Sourcefire 3D System Installation Guide 133
Hardware Specifications
Sourcefire Defense Centers
Chapter 6
The DC1500 System Components: Rear View table describes the features that
appear on the rear of the appliance.
The 10/100/1000Mbps management interface is located on the rear of the
appliance. The
DC1500 Management Interface LEDs table describes the LEDs
associated with the management interface.
DC1500 System Components: Rear View
FEATURE DESCRIPTION
Power supply Provides power to the Defense Center through an AC power source.
VGA port
USB ports
Allows you to attach a monitor, keyboard, and mouse to the Defense Center.
10/100/1000Mbps
Ethernet
management
interface
Provides for an out-of-band management network connection. The
management interface is used for maintenance and configuration purposes
only and is not intended to carry service traffic.
Alternate eStreamer
interface
Provides an alternate interface for the eStreamer client
RJ45 serial port Allows you to establish a direct workstation-to-appliance connection (using an
RJ45 to DB-9 adapter) for direct access to all of the management services on
the appliance. The RJ45 serial port is used for maintenance and configuration
purposes only and is not intended to carry service traffic. See the DC1500
Serial Port Pin Assignments table on page 134.
IMPORTANT! You cannot use the front and the rear panel serial ports at the
same time.
DC1500 Management Interface LEDs
LED DESCRIPTION
Left (link) Indicates whether the link is up:
If the light is on, the link is up.
No light indicates there is no link.
Right (activity) Indicates activity on the port:
A blinking light indicates activity.
No light indicates there is no activity.
