Version 5.2 Sourcefire 3D System Installation Guide 160
Hardware Specifications
Sourcefire 7000 Series Devices
Chapter 6
The 10/100/1000 management interface is located on the rear of the appliance.
The following table describes the LEDs associated with the management
interface.
The power supply modules are located on the rear of the appliance. The following
table describes the LED associated with the power supply.
3D7110 and 3D7120 Management Interface LEDs
LED DESCRIPTION
Left (activity) Indicates activity on the port:
• A blinking light indicates activity.
• No light indicates there is no activity.
Right (link) Indicates whether the link is up:
• A light indicates the link is up.
• No light indicates there is no link.
3D7110 and 3D7120 Power Supply LED
LED DESCRIPTION
Off The power cord is not plugged in.
Red No power supplied to this module.
OR
A power supply critical event, such as module failure, a
blown fuse, or a fan failure; the power supply shuts down.
Blinking red A power supply warning event, such as high temperature
or a slow fan; the power supply continues to operate.
Blinking green AC input is present; volts on standby, the power supply is
switched off.
Green The power supply is plugged in and on.
