10-14 Parameter Specification
605C Frequency Inverter
Tag (MMI) Name Block Type Range ID Notes
527 PRESET 5 INPUT 6 PRESET 5 INT -300.00 to 300.00 % en
528 PRESET 5 INPUT 7 PRESET 5 INT -300.00 to 300.00 % eo
529 PRESET 5 SELECT PRESET 5 ENUM Same as tag 355 ep
530 PRESET 5 OUTPUT1 PRESET 5 INT xxx.xx % eq Output
531 PRESET 5 OUTPUT2 PRESET 5 INT xxx.xx % er Output
532 PRESET 6 INPUT 0 PRESET 6 INT -300.00 to 300.00 % es
533 PRESET 6 INPUT 1 PRESET 6 INT -300.00 to 300.00 % et
534 PRESET 6 INPUT 2 PRESET 6 INT -300.00 to 300.00 % eu
535 PRESET 6 INPUT 3 PRESET 6 INT -300.00 to 300.00 % ev
536 PRESET 6 INPUT 4 PRESET 6 INT -300.00 to 300.00 % ew
537 PRESET 6 INPUT 5 PRESET 6 INT -300.00 to 300.00 % ex
538 PRESET 6 INPUT 6 PRESET 6 INT -300.00 to 300.00 % ey
539 PRESET 6 INPUT 7 PRESET 6 INT -300.00 to 300.00 % ez
540 PRESET 6 SELECT PRESET 6 ENUM Same as tag 355 f0
541 PRESET 6 OUTPUT1 PRESET 6 INT xxx.xx % f1 Output
542 PRESET 6 OUTPUT2 PRESET 6 INT xxx.xx % f2 Output
543 PRESET 7 INPUT 0 PRESET 7 INT -300.00 to 300.00 % f3
544 PRESET 7 INPUT 1 PRESET 7 INT -300.00 to 300.00 % f4
545 PRESET 7 INPUT 2 PRESET 7 INT -300.00 to 300.00 % f5
546 PRESET 7 INPUT 3 PRESET 7 INT -300.00 to 300.00 % f6
547 PRESET 7 INPUT 4 PRESET 7 INT -300.00 to 300.00 % f7
548 PRESET 7 INPUT 5 PRESET 7 INT -300.00 to 300.00 % f8
549 PRESET 7 INPUT 6 PRESET 7 INT -300.00 to 300.00 % f9
550 PRESET 7 INPUT 7 PRESET 7 INT -300.00 to 300.00 % fa
551 PRESET 7 SELECT PRESET 7 ENUM Same as tag 355 fb
552 PRESET 7 OUTPUT1 PRESET 7 INT xxx.xx % fc Output
553 PRESET 7 OUTPUT2 PRESET 7 INT xxx.xx % fd Output
554 PRESET 8 INPUT 0 PRESET 8 INT -300.00 to 300.00 % fe
555 PRESET 8 INPUT 1 PRESET 8 INT -300.00 to 300.00 % ff
556 PRESET 8 INPUT 2 PRESET 8 INT -300.00 to 300.00 % fg
557 PRESET 8 INPUT 3 PRESET 8 INT -300.00 to 300.00 % fh
558 PRESET 8 INPUT 4 PRESET 8 INT -300.00 to 300.00 % fi
559 PRESET 8 INPUT 5 PRESET 8 INT -300.00 to 300.00 % fj
560 PRESET 8 INPUT 6 PRESET 8 INT -300.00 to 300.00 % fk
561 PRESET 8 INPUT 7 PRESET 8 INT -300.00 to 300.00 % fl
562 PRESET 8 SELECT PRESET 8 ENUM Same as tag 355 fm
563 PRESET 8 OUTPUT1 PRESET 8 INT xxx.xx % fn Output
564 PRESET 8 OUTPUT2 PRESET 8 INT xxx.xx % fo Output
565 ENCODER MODE ENCODER ENUM 0 : QUADRATURE
1 : CLOCK/DIR
2 : CLOCK
fp
566 ENCODER LINES ENCODER INT 1 to 10000 fq 3
567 ENCODER INVERT ENCODER BOOL FALSE / TRUE fr
568 ENCODER SPEED ENCODER INT xxxx.x Hz fs Output
569 ENCODER SPEED ENCODER INT xxxxx n/min ft Output
570 FLY CATCH ENABLE FLY CATCHING BOOL FALSE / TRUE fu
571 FLY START MODE FLY CATCHING ENUM 0 : ALWAYS
1 : TRIP OR POWERUP
2 : TRIP
fv
