Parameter Specification 10-15
605C Frequency Inverter
Tag (MMI) Name Block Type Range ID Notes
572 FLY SEARCH MODE FLY CATCHING ENUM 0 : BIDIRECTIONAL
1 : UNIDIRECTIONAL
fw
573 FLY SEARCH VOLTS FLY CATCHING INT 0.00 to 100.00 % fx 3
574 FLY SEARCH TIME FLY CATCHING INT 0.1 to 60.0 s fy 3
575 FLY MIN SPEED FLY CATCHING INT 5.0 to 480.0 Hz fz
576 FLY CATCH ACTIVE FLY CATCHING BOOL FALSE / TRUE g0 Output
577 INJ FREQUENCY INJ BRAKING INT 1.0 to 480.0 Hz g1 3
578 INJ I-LIM LEVEL INJ BRAKING INT 50.00 to 150.00 % g2
579 INJ DC PULSE INJ BRAKING INT 0.0 to 100.0 s g3 3
580 INJ FINAL DC INJ BRAKING INT 0.0 to 10.0 s g4 3
581 INJ DC LEVEL INJ BRAKING INT 0.00 to 25.00 % g5 3
582 INJ TIMEOUT INJ BRAKING INT 0.0 to 600.0 s g6
583 INJ ACTIVE INJ BRAKING BOOL FALSE / TRUE g7 Output
584 BRAKE ON LOAD BRAKE CONTROL INT 0.00 to 150.00 % g8
585 BRAKE ON FREQ BRAKE CONTROL INT 0.0 to 480.0 Hz g9
586 BRAKE OFF FREQ BRAKE CONTROL INT 0.0 to 480.0 Hz ga
587 BRAKE RELEASE BRAKE CONTROL BOOL FALSE / TRUE gb Output
588 BRAKE ON HOLD BRAKE CONTROL INT 0.00 to 60.00 s gc
589 BRAKE OFF HOLD BRAKE CONTROL INT 0.00 to 60.00 s gd
590 BRAKE HOLD BRAKE CONTROL BOOL FALSE / TRUE ge Output
591 DRIVE FREQUENCY PATTERN GEN INT xxxx.x Hz gf Output
592 VOLTS PATTERN GEN INT xxxx.x V gg Output
593 BOOST PATTERN GEN INT xxxx.x V gh Output
595 VOLTAGE MODE VOLTAGE CONTROL ENUM 0 : NONE
1 : FIXED
2 : AUTOMATIC
gj 7
596 SUPPLY VOLTAGE VECTOR FLUXING INT xxxx.x V gk Output
598 OUTPUT MULTIPLEXER WORD 0000 to FFFF gm Output
599 INPUT DEMULTIPLEXER WORD 0000 to FFFF gn
600 ULC ENABLE UNDERLAP COMP BOOL FALSE / TRUE go
603 AUTOTUNE ENABLE AUTOTUNE BOOL FALSE / TRUE gr
604 AUTOTUNE ACTIVE AUTOTUNE BOOL FALSE / TRUE gs Output
608 AR PENDING AUTO RESTART BOOL FALSE / TRUE gw Output
609 AR TRIGGERS 1 AUTO RESTART WORD 0000 to FFFF gx
610 AR INITIAL DLY 1 AUTO RESTART INT 0.0 to 600.0 s gy
611 AR ENABLE AUTO RESTART BOOL FALSE / TRUE gz
612 AR ATTEMPTS AUTO RESTART INT 1 to 10 h0
613 AR ATTEMPT DLY 1 AUTO RESTART INT 0.0 to 600.0 s h1
614 AR ATTEMPTS LEFT AUTO RESTART INT xxxxx h2 Output
615 AR TIME LEFT AUTO RESTART INT xxxx.x s h3 Output
616 AR RESTARTING AUTO RESTART BOOL FALSE / TRUE h4 Output
623 REGEN I LIMIT CURRENT LIMIT INT -150.00 to 0.00 % hb
626 OP MENU 2 OPERATOR MENU TAG 0 to 1002 he
627 OP MENU 3 OPERATOR MENU TAG 0 to 1002 hf
628 OP MENU 4 OPERATOR MENU TAG 0 to 1002 hg
629 OP MENU 5 OPERATOR MENU TAG 0 to 1002 hh
630 OP MENU 6 OPERATOR MENU TAG 0 to 1002 hi
631 OP MENU 7 OPERATOR MENU TAG 0 to 1002 hj
632 OP MENU 8 OPERATOR MENU TAG 0 to 1002 hk
