10-16 Parameter Specification
605C Frequency Inverter
Tag (MMI) Name Block Type Range ID Notes
633 OP MENU 9 OPERATOR MENU TAG 0 to 1002 hl
634 OP MENU 10 OPERATOR MENU TAG 0 to 1002 hm
635 OP MENU 11 OPERATOR MENU TAG 0 to 1002 hn
636 OP MENU 12 OPERATOR MENU TAG 0 to 1002 ho
637 OP MENU 13 OPERATOR MENU TAG 0 to 1002 hp
638 OP MENU 14 OPERATOR MENU TAG 0 to 1002 hq
639 OP MENU 15 OPERATOR MENU TAG 0 to 1002 hr
641 INPUT 0 MULTIPLEXER BOOL FALSE / TRUE ht
642 INPUT 1 MULTIPLEXER BOOL FALSE / TRUE hu
643 INPUT 2 MULTIPLEXER BOOL FALSE / TRUE hv
644 INPUT 3 MULTIPLEXER BOOL FALSE / TRUE hw
645 INPUT 4 MULTIPLEXER BOOL FALSE / TRUE hx
646 INPUT 5 MULTIPLEXER BOOL FALSE / TRUE hy
647 INPUT 6 MULTIPLEXER BOOL FALSE / TRUE hz
648 INPUT 7 MULTIPLEXER BOOL FALSE / TRUE i0
649 INPUT 8 MULTIPLEXER BOOL FALSE / TRUE i1
650 INPUT 9 MULTIPLEXER BOOL FALSE / TRUE i2
651 INPUT 10 MULTIPLEXER BOOL FALSE / TRUE i3
652 INPUT 11 MULTIPLEXER BOOL FALSE / TRUE i4
653 INPUT 12 MULTIPLEXER BOOL FALSE / TRUE i5
654 INPUT 13 MULTIPLEXER BOOL FALSE / TRUE i6
655 INPUT 14 MULTIPLEXER BOOL FALSE / TRUE i7
656 INPUT 15 MULTIPLEXER BOOL FALSE / TRUE i8
657 OUTPUT 0 DEMULTIPLEXER BOOL FALSE / TRUE i9 Output
658 OUTPUT 1 DEMULTIPLEXER BOOL FALSE / TRUE ia Output
659 OUTPUT 2 DEMULTIPLEXER BOOL FALSE / TRUE ib Output
660 OUTPUT 3 DEMULTIPLEXER BOOL FALSE / TRUE ic Output
661 OUTPUT 4 DEMULTIPLEXER BOOL FALSE / TRUE id Output
662 OUTPUT 5 DEMULTIPLEXER BOOL FALSE / TRUE ie Output
663 OUTPUT 6 DEMULTIPLEXER BOOL FALSE / TRUE if Output
664 OUTPUT 7 DEMULTIPLEXER BOOL FALSE / TRUE ig Output
665 OUTPUT 8 DEMULTIPLEXER BOOL FALSE / TRUE ih Output
666 OUTPUT 9 DEMULTIPLEXER BOOL FALSE / TRUE ii Output
667 OUTPUT 10 DEMULTIPLEXER BOOL FALSE / TRUE ij Output
668 OUTPUT 11 DEMULTIPLEXER BOOL FALSE / TRUE ik Output
669 OUTPUT 12 DEMULTIPLEXER BOOL FALSE / TRUE il Output
670 OUTPUT 13 DEMULTIPLEXER BOOL FALSE / TRUE im Output
671 OUTPUT 14 DEMULTIPLEXER BOOL FALSE / TRUE in Output
672 OUTPUT 15 DEMULTIPLEXER BOOL FALSE / TRUE io Output
673 COEFFICIENT B CUSTOM SCREEN 2 INT 1 to 30000 ip
674 HIGH LIMIT CUSTOM SCREEN 2 INT -30000 to 30000 iq
675 LOW LIMIT CUSTOM SCREEN 2 INT -30000 to 30000 ir
676 FORMULA CUSTOM SCREEN 2 ENUM Same as tag 125 is
677 AR TRIGGERS 2 AUTO RESTART WORD 0000 to FFFF it
678 AR INITIAL DLY 2 AUTO RESTART INT 0.0 to 600.0 s iu
679 AR ATTEMPT DLY 2 AUTO RESTART INT 0.0 to 600.0 s iv
680 SKIP FREQ BAND 2 SKIP FREQUENCIES INT 0.0 to 480.0 Hz iw
681 SKIP FREQ BAND 3 SKIP FREQUENCIES INT 0.0 to 480.0 Hz ix
