Parameter Specification 10-17
605C Frequency Inverter
Tag (MMI) Name Block Type Range ID Notes
682 SKIP FREQ BAND 4 SKIP FREQUENCIES INT 0.0 to 480.0 Hz iy
686 REGEN LIM ENABLE CURRENT LIMIT BOOL FALSE / TRUE j2 7
689 AUTOTUNE MODE AUTOTUNE ENUM 0 : USER NO LOAD I
1 : CALC NO LOAD I
j5 7
691 SRAMP CONTINUOUS SYSTEM RAMP BOOL FALSE / TRUE j7
692 SRAMP ACCEL SYSTEM RAMP INT 0.00 to 100.00 % j8
693 SRAMP DECEL SYSTEM RAMP INT 0.00 to 100.00 % j9
694 SRAMP JERK 1 SYSTEM RAMP INT 0.00 to 100.00 % ja
695 SRAMP JERK 2 SYSTEM RAMP INT 0.00 to 100.00 % jb
696 SRAMP JERK 3 SYSTEM RAMP INT 0.00 to 100.00 % jc
697 SRAMP JERK 4 SYSTEM RAMP INT 0.00 to 100.00 % jd
698 RAMPING SYSTEM RAMP BOOL FALSE / TRUE je Output
709 FLY REFLUX TIME FLY CATCHING INT 0.1 to 20.0 s jp
710 INJ DEFLUX TIME INJ BRAKING INT 0.1 to 20.0 s jq 3
711 AIN 3 BREAK ENBL ANALOG INPUT 3 BOOL FALSE / TRUE jr
712 AIN 3 TYPE ANALOG INPUT 3 ENUM Same as tag 13 js 7
713 AIN 3 SCALE ANALOG INPUT 3 INT -300.00 to 300.00 % jt
714 AIN 3 OFFSET ANALOG INPUT 3 INT -300.00 to 300.00 % ju
715 AIN 3 VALUE ANALOG INPUT 3 INT xxx.xx % jv Output
716 AIN 3 BREAK VAL ANALOG INPUT 3 INT -300.00 to 300.00 % jw
717 AIN 3 BREAK ANALOG INPUT 3 BOOL FALSE / TRUE jx Output
718 AIN 4 BREAK ENBL ANALOG INPUT 4 BOOL FALSE / TRUE jy
719 AIN 4 TYPE ANALOG INPUT 4 ENUM 0 : 0..+10 V
1 : +2..+10 V
2 : 0..+5 V
3 : +1..+5 V
jz 7
720 AIN 4 SCALE ANALOG INPUT 4 INT -300.00 to 300.00 % k0
721 AIN 4 OFFSET ANALOG INPUT 4 INT -300.00 to 300.00 % k1
722 AIN 4 VALUE ANALOG INPUT 4 INT xxx.xx % k2 Output
723 AIN 4 BREAK VAL ANALOG INPUT 4 INT -300.00 to 300.00 % k3
724 AIN 4 BREAK ANALOG INPUT 4 BOOL FALSE / TRUE k4 Output
725 DIN 6 INVERT DIGITAL INPUT 6 BOOL FALSE / TRUE k5
726 DIN 6 VALUE DIGITAL INPUT 6 BOOL FALSE / TRUE k6 Output
727 DIN 7 INVERT DIGITAL INPUT 7 BOOL FALSE / TRUE k7
728 DIN 7 VALUE DIGITAL INPUT 7 BOOL FALSE / TRUE k8 Output
729 DIN 8 INVERT DIGITAL INPUT 8 BOOL FALSE / TRUE k9
730 DIN 8 VALUE DIGITAL INPUT 8 BOOL FALSE / TRUE ka Output
731 AOUT 2 VALUE ANALOG OUTPUT 2 INT -300.00 to 300.00 % kb
732 AOUT 2 SCALE ANALOG OUTPUT 2 INT -300.00 to 300.00 % kc
733 AOUT 2 OFFSET ANALOG OUTPUT 2 INT -300.00 to 300.00 % kd
734 AOUT 2 ABS ANALOG OUTPUT 2 BOOL FALSE / TRUE ke
735 AOUT 2 TYPE ANALOG OUTPUT 2 ENUM 0 : 0..+10 V
1 : -10..+10 V
kf 7
736 DOUT 3 INVERT DIGITAL OUTPUT 3 BOOL FALSE / TRUE kg
737 DOUT 3 VALUE DIGITAL OUTPUT 3 BOOL FALSE / TRUE kh
739 INJ BASE VOLTS INJ BRAKING INT 0.00 to 115.47 % kj 3
740 ACTIVE TRIPS+ TRIPS STATUS WORD 0000 to FFFF kk Output
741 TRIP WARNINGS+ TRIPS STATUS WORD 0000 to FFFF kl Output
742 DISABLED TRIPS+ TRIPS STATUS WORD 0000 to FFFF km
744 AR TRIGGERS+ 1 AUTO RESTART WORD 0000 to FFFF ko
