UM0306 Controller area network (bxCAN)

307/519

Bit 1

TXOK0: Transmission OK of Mailbox0

The hardware updates this bit after each transmission attempt.

0: The previous transmission failed

1: The previous transmission was successful

This bit is set by hardware when the transmission request on mailbox 1 has been

completed successfully. Please refer to Figure 124

Bit 0

RQCP0: Request Completed Mailbox0

Set by hardware when the last request (transmit or abort) has been performed.

Cleared by software writing a “1” or by hardware on transmission request (TXRQ0

set in CAN_TI0R register).

Clearing this bit clears all the status bits (TXOK0, ALST0 and TERR0) for Mailbox
