UM0306 Controller area network (bxCAN)

317/519

Rx FIFO mailbox identifier register (CAN_RIxR) (x=0..1)

Address Offsets: 1B0h, 1C0h

Reset Value: xxh

Note: All RX registers are write protected.

Bits 15:8

DATA5[7:0]: Data Byte 5

Data byte 5 of the message.

Bits 7:0

DATA4[7:0]: Data Byte 4

Data byte 4 of the message.

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

STID[10:0] EXID[17:13]

rrrrrrrrrrrrrrrr

1514131211109876543210

EXID[12:0] IDE RTR Res.

rrrrrrrrrrrrrrr

Bits 31:21

STID[10:0]: Standard Identifier

The standard part of the identifier.

Bits 20:3

EXID[17:0]: Extended Identifier

The extended part of the identifier.

Bit 2

IDE: Extended Identifier

This bit defines the identifier type of message in the mailbox.

0: Standard identifier.

1: Extended identifier.

Bit 1

RTR: Remote Transmission Request

0: Data frame

1: Remote frame

Bit 0 Reserved
