UM0306 Controller area network (bxCAN)

319/519

Receive FIFO mailbox data high register (CAN_RDHxR) (x=0..1)

Address Offsets: 1BCh, 1CCh

Reset Value: xxh

Note: All RX registers are write protected.

Bits 31:24

DATA3[7:0]: Data Byte 3

Data byte 3 of the message.

Bits 23:16

DATA2[7:0]: Data Byte 2

Data byte 2 of the message.

Bits 15:8

DATA1[7:0]: Data Byte 1

Data byte 1 of the message.

Bits 7:0

DATA0[7:0]: Data Byte 0

Data byte 0 of the message.

A message can contain from 0 to 8 data bytes and starts with byte 0.

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

DATA7[7:0] DATA6[7:0]

rrrrrrrrrrrrrrrr

1514131211109876543210

DATA5[7:0] DATA4[7:0]

rrrrrrrrrrrrrrrr

Bits 31:24

DATA7[7:0]: Data Byte 7

Data byte 3 of the message.

Bits 23:16

DATA6[7:0]: Data Byte 6

Data byte 2 of the message.

Bits 15:8

DATA5[7:0]: Data Byte 5

Data byte 1 of the message.

Bits 7:0

DATA4[7:0]: Data Byte 4

Data byte 0 of the message.
