UM0306 USB full speed device interface (USB)
443/519
Bits 10:9
EP_TYPE[1:0]: Endpoint type
These bits configure the behavior of this endpoint as described in Table 60: Endpoint
type encoding on page 445. Endpoint 0 must always be a control endpoint and each
USB function must have at least one control endpoint which has address 0, but there
may be other control endpoints if required. Only control endpoints handle SETUP
transactions, which are ignored by endpoints of other kinds. SETUP transactions
cannot be answered with NAK or STALL. If a control endpoint is defined as NAK, the
USB Peripheral will not answer, simulating a receive error, in the receive direction
when a SETUP transaction is received. If the control endpoint is defined as STALL in
the receive direction, then the SETUP packet will be accepted anyway, transferring
data and issuing the CTR interrupt. The reception of OUT transactions is handled in
the normal way, even if the endpoint is a control one.
Bulk and interrupt endpoints have very similar behavior and they differ only in the
special feature available using the EP_KIND configuration bit.
The usage of Isochronous endpoints is explained in Section 18.5.4: Isochronous
transfers
Bit 8
EP_KIND: Endpoint Kind
The meaning of this bit depends on the endpoint type configured by the EP_TYPE bits.
Ta ble 6 1 summarizes the different meanings.
DBL_BUF: This bit is set by the software to enable the double-buffering feature for this
bulk endpoint. The usage of double-buffered bulk endpoints is explained in
Section 18.5.3: Double-buffered endpoints.
STATUS_OUT: This bit is set by the software to indicate that a status out transaction is
expected: in this case all OUT transactions containing more than zero data bytes are
answered ‘STALL’ instead of ‘ACK’. This bit may be used to improve the robustness of
the application to protocol errors during control transfers and its usage is intended for
control endpoints only. When STATUS_OUT is reset, OUT transactions can have any
number of bytes, as required.
Bit 7
CTR_TX: Correct Transfer for transmission
This bit is set by the hardware when an IN transaction is successfully completed on
this endpoint; the software can only clear this bit. If the CTRM bit in the register is set
accordingly, a generic interrupt condition is generated together with the endpoint
related interrupt condition, which is always activated.
A transaction ended with a NAK or STALL handshake does not set this bit, since no
data is actually transferred, as in the case of protocol errors or data toggle
mismatches.
This bit is read/write but only ‘0’ can be written.
