USB full speed device interface (USB) UM0306
442/519
Bit 15
CTR_RX: Correct Transfer for reception
This bit is set by the hardware when an OUT/SETUP transaction is successfully
completed on this endpoint; the software can only clear this bit. If the CTRM bit in
register is set accordingly, a generic interrupt condition is generated together with the
endpoint related interrupt condition, which is always activated. The type of occurred
transaction, OUT or SETUP, can be determined from the SETUP bit described below.
A transaction ended with a NAK or STALL handshake does not set this bit, since no
data is actually transferred, as in the case of protocol errors or data toggle
mismatches.
This bit is read/write but only ‘0’ can be written, writing 1 has no effect.
Bit 14
DTOG_RX: Data Toggle, for reception transfers
If the endpoint is not Isochronous, this bit contains the expected value of the data
toggle bit (0=DATA0, 1=DATA1) for the next data packet to be received. Hardware
toggles this bit, when the ACK handshake is sent to the USB host, following a data
packet reception having a matching data PID value; if the endpoint is defined as a
control one, hardware clears this bit at the reception of a SETUP PID addressed to this
endpoint.
If the endpoint is using the double-buffering feature this bit is used to support packet
buffer swapping too (Refer to Section 18.5.3: Double-buffered endpoints).
If the endpoint is Isochronous, this bit is used only to support packet buffer swapping
since no data toggling is used for this sort of endpoints and only DATA0 packet are
transmitted (Refer to Section 18.5.4: Isochronous transfers). Hardware toggles this bit
just after the end of data packet reception, since no handshake is used for isochronous
transfers.
This bit can also be toggled by the software to initialize its value (mandatory when the
endpoint is not a control one) or to force specific data toggle/packet buffer usage.
When the application software writes ‘0’, the value of DTOG_RX remains unchanged,
while writing ‘1’ makes the bit value toggle. This bit is read/write but it can be only
toggled by writing 1.
Bits 13:12
STAT_RX [1:0]: Status bits, for reception transfers
These bits contain information about the endpoint status, which are listed in Table 59:
Reception status encoding on page 444.These bits can be toggled by software to
initialize their value. When the application software writes ‘0’, the value remains
unchanged, while writing ‘1’ makes the bit value toggle. Hardware sets the STAT_RX
bits to NAK when a correct transfer has occurred (CTR_RX=1) corresponding to a
OUT or SETUP (control only) transaction addressed to this endpoint, so the software
has the time to elaborate the received data before it acknowledge a new transaction
Double-buffered bulk endpoints implement a special transaction flow control, which
control the status based upon buffer availability condition (Refer to Section 18.5.3:
Double-buffered endpoints).
If the endpoint is defined as Isochronous, its status can be only “VALID” or
“DISABLED”, so that the hardware cannot change the status of the endpoint after a
successful transaction. If the software sets the STAT_RX bits to ‘STALL’ or ‘NAK’ for an
Isochronous endpoint, the USB Peripheral behavior is not defined. These bits are
read/write but they can be only toggled by writing ‘1’.
Bit 11
SETUP: Setup transaction completed
This bit is read-only and it is set by the hardware when the last completed transaction
is a SETUP. This bit changes its value only for control endpoints. It must be examined,
in the case of a successful receive transaction (CTR_RX event), to determine the type
of transaction occurred. To protect the interrupt service routine from the changes in
SETUP bits due to next incoming tokens, this bit is kept frozen while CTR_RX bit is at
1; its state changes when CTR_RX is at 0. This bit is read-only.
