Stihl TS 700, TS 800 User Manual

4 TS 700, TS 800
3. Specifications
3.1 Power unit
TS 700, TS 800
Displacement: 98.5 cm
3
Bore: 56 mm
Stroke: 40 mm
Engine power to ISO 7293: 5.0 kW (6.8 HP)
at 9300 rpm
Nominal spindle speed 4620 rpm
Idle speed: 2200 rpm
Clutch: Centrifugal clutch without linings
Clutch engages at: 3200 rpm
Crankcase leakage test
at excess pressure: p
ü
= 0.5 bar
under vacuum: p
u
= 0.5 bar
3.2 Fuel system
Carburetor leakage test at
excess pressure: p
ü
= 0.8 bar
Operation of tank vent at
excess pressure: p
ü
= 0.3 bar
Fuel: as specified in instruction
manual
3.3 Ignition system
Air gap between ignition
module and fanwheel: 0.15...0.3 mm
Spark plug (interference
suppressed):
Bosch WSR 6F
NGK BPMR 7 A
Electrode gap: 0.5 mm
