Stryker LUCAS 3 Service Manual

LUCAS
®
3 Chest Compression System – Service Manual
3328798-002, ©2017 Physio-Control, Inc.
Page 30 of 91
- Example LUCAS 3 Version 3.0 (Part No: 250039-00) –
- LUCAS 3 Version 3.1 (Part No: 250041-00) –
1. Click START to calibrate Linear Sensor.
2. When the Calibration process starts, the progress will be shown in the Control CPU’s window. When the
calibration is done, the result is shown in the lower right corner.
- POT CAL In Progress - - POT CAL Done - - POT CAL Values –
3. Click Store View to print the result.
POT CAL
Acceptable Values:
C: < 6%
P: < 3.1%

Stryker LUCAS 3 Specifications

General

Device Type	Chest Compression System
Power Source	Rechargeable Lithium-ion Battery
Compression Depth	5.3 ± 0.2 cm (2.1 ± 0.1 in)
Battery Life	45 minutes of operation
Battery Charge Time	Approximately 4 hours
Operating Modes	Pause
Patient Size	Fits most adult patients
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	–20 to +60 °C (–4 to 140 °F)
IP Rating	IP43
Compression Rate	100 compressions per minute
