Stryker LUCAS 3 Service Manual

LUCAS
®
3 Chest Compression System – Service Manual
3328798-002, ©2017 Physio-Control, Inc.
Page 52 of 91
21576-000095
LUCAS 3 SUPPORT LEG, STRYKER 160408-01
Including angle shafts, strap
holders, snap rings, and torsion-
spring
21576-000082 LUCAS 3 CONTROL BOARD 160409-00
Including bracket, and 3 plastic
screws for communication board.
21576-000091 LUCAS 3 PROTECTIVE BOARD 160410-00 Including bracket
21576-000007 LUCAS 2 DRIVE BELT 150411-00
21576-000055 BELT COVER 100654-00
21576-000070
LUCAS 2 INTERNAL
COMMUNICATION CABLE 2.2
150413-20
15-pin cable between control
board and protective board
21576-000020
LUCAS 2 HOOD COMMUNICATION
CABLE
150414-00
Flat cable between hood and
protective board
21576-000025
LUCAS 2 BATTERY CONNECTOR
BOARD
150415-00 Including O-rings
21576-000083 LUCAS 3 FRAME ASSY 160416-00
Main body with support legs
mounted
21576-000089 LUCAS HOOD BRACKET 150420-00
21576-000096
ASSEMBLY, FRAME, LUCAS 3
STRYKER
160416-01
Main body with support legs
mounted
21576-000072 LUCAS 2 POWER INLET 2.2 150417-20
DC-inlet connector (main body)
including cable
21576-000085 LUCAS 3 COMMUNICATION BOARD 160420-00
Includes communication board
and 3 plastic screws.
21576-000097
LUCAS 3 VERSION 3.1
COMMUNICATION BOARD
160420-01
Includes communication board
and 3 plastic screws.
21576-000087 LUCAS 3 ANTENNA ASSEMBLY 160422-00
Includes 2 cable ties and 2
transfer tapes
21576-000077 SPARE PART PADDING LUCAS3 160421-00 Shipping box padding material
21576-000076 SHIPPING BOX 100938-00
21576-000093 SHIPPING BOX, STRYKER 100938-01
21576-000084 LUCAS 3 MAIN BODY COMPLETE 160419-00 Main body without support legs
21576-000090 SD MEMORY CARD 150421-00
Other Orderable Spare Parts
Catalog # Description Drawing # Note
21576-000047
SCREW PT K40X12
WN 1452 A2
10150120-43
QTY: 4, Used to attach Hood to main body
21576-000049
WASHER 3X10X3.4
ARAN LOCK
10150085-29
QTY: 4, Used to attach Thread Plate to main
body
21576-000050
AXEL-ANGLE SHAFT
240-3
QTY: 4, Used to attach Support Leg to Main
Body

Stryker LUCAS 3 Specifications

General

Device Type	Chest Compression System
Power Source	Rechargeable Lithium-ion Battery
Compression Depth	5.3 ± 0.2 cm (2.1 ± 0.1 in)
Battery Life	45 minutes of operation
Battery Charge Time	Approximately 4 hours
Operating Modes	Pause
Patient Size	Fits most adult patients
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	–20 to +60 °C (–4 to 140 °F)
IP Rating	IP43
Compression Rate	100 compressions per minute
