Stryker LUCAS 3 Service Manual

LUCAS
®
3 Chest Compression System – Service Manual
3328798-002, ©2017 Physio-Control, Inc.
Page 45 of 91
RUN_TIMEDOWN
No=0x48
Time Down too
long or too
Shallow.
(50
consecutive
strokes)
Too high load and/or
too low battery
voltage. Motor fault.
Check load
and motor.
High priority
Alarm.
Compressions out
of range
RUN_POTCAL
No=0x4A
Potentiometer
Calibration
fault, not
moved or pot
read.
(See ID in
Control vector,
at position
139).
Movement fault at
calibration or large
potentiometer fault
Check
potentiometer
connections
and
mechanical
movement,
repeat
calibration.
At
Calibration:
High priority
Alarm.
Internal fault -
contact Technical
Support
RUN_NO_POTCAL
No=0x4B
Potentiometer
not calibrated
(See ID in
Control vector,
at position
139).
Not calibrated or other
calibration fault.
Check for
other fault or
perform a
new
calibration.
Delayed
(10s) High
priority
Alarm.
Internal fault -
contact Technical
Support
RUN_P_STOP
No=0x4C
Protective
system have
stopped
operation
Protective system
error.
Check
Protective
system error
codes for
cause.
High priority
Alarm.
Warnings from Control CPU
Warning Code
Explanation
Probable Cause
Module to check
/ replace
User
Observation
LRG Text
T1_START_COM
No=0x13
No
Communication
from Protective
and/or Battery-
Charger CPU's at
first start.
I2C communication
startup faults. Delayed
start of Protective or
Charger CPU.
Check cable
between boards
or Protective
board.
Prolonged
startup test
time.
T1_C_INITCURR
No=0x20
High Current
detected at Start,
next automatic
restart worked
well.
Fault read current to
motor or unstable
driver FET’s +/- 12V
supply.
If needed replace
Control board.
Prolonged
startup test
time.
T1_P_STATE_1
No=0x21
Start of Release
Test time out
(from Protective),
next automatic
restart worked
well.
Protective start
delayed. I2C
communication startup
faults.
Check Cable
between boards.
Protective board.
Prolonged
startup test
time.
T1_C_RELEASE
No=0x22
Current detected
at release/disable
test by Control at
first start.
P45 module delayed
or loose cable
between boards.
Cable between
boards. Check
Protective
voltages.
Prolonged
startup test
time.
T1_P_STATE_3
No=0x23
Start of Current
Test time out
(from Protective)
at first start.
Current detected
by Protective
Current first detected
by Protective or I2C
communication faults.
Cable between
boards.
Protective board.
Prolonged
startup test
time.

Stryker LUCAS 3 Specifications

General

Device Type	Chest Compression System
Power Source	Rechargeable Lithium-ion Battery
Compression Depth	5.3 ± 0.2 cm (2.1 ± 0.1 in)
Battery Life	45 minutes of operation
Battery Charge Time	Approximately 4 hours
Operating Modes	Pause
Patient Size	Fits most adult patients
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	–20 to +60 °C (–4 to 140 °F)
IP Rating	IP43
Compression Rate	100 compressions per minute
