Stryker LUCAS 3 Service Manual

LUCAS
®
3 Chest Compression System – Service Manual
3328798-002, ©2017 Physio-Control, Inc.
Page 44 of 91
INT_C_POTCAL
No=0x3D
Control
Potentiometer
linearity fault
Too un-linear Control
potentiometer or
influenced at
calibration
Repeat
calibration or
replace
compression
module.
Delayed
(10s) High
priority
Alarm.
Internal fault -
contact Technical
Support
INT_P_POTCAL
No=0x3E
Protective
Potentiometer
linearity fault
Too un-linear
Protective
potentiometer or
influenced at
calibration
Repeat
calibration or
replace
compression
module.
Delayed
(10s) High
priority
Alarm.
Internal fault -
contact Technical
Support
RUN_TIMEOUT
No=0x40
Piston not
moved during
active (moving)
mode ( > 1s)
Disconnected motor
(mechanical/electrical)
or locked
compression module.
Compression
module.
Motor
connections.
High priority
Alarm.
Disruption of
Suction Cup
RUN_TOO_DEEP
No=0x41
Piston too deep
Control potentiometer
fault. Rough or
influenced
compression
movement at run with
no load. Hall signal
missing.
Assure un-
influenced
movement of
the
compression
module (re-
test). Check
Hall. Replace
motor or
compression
module.
High priority
Alarm.
In Pause:
Disruption of
Suction Cup
In Active:
Compressions out
of range
RUN_TOO_SHALLOW
No=0x42
Piston too
shallow
(50
consecutive
strokes @ 100
bpm)
50 strokes < Target
stroke length - 10mm
(@ 100bpm). Too
high load and/or too
low battery voltage.
Locked module.
Assure
correct
movement of
the
compression
module. If
needed
replace the
compression
module.
High priority
Alarm.
Compressions out
of range
RUN_RATIO
No=0x44
Piston Ratio
fault
(50
consecutive
strokes)
Too high load. Ratio
fault (Preset Ratio +/-
20%) at 50
consecutive strokes.
Check load.
High priority
Alarm.
Compressions out
of range
RUN_PROTECTIVE
No=0x45
Halt or reverse
by Protective
System during
active (moving)
mode ( > 1s)
Active mode disabled
by the Protective
system.
Check
Protective
error’s for
cause.
High priority
Alarm.
RUN_TIMEUP
No=0x47
Time Up too
long > 0.15s
(50
consecutive
strokes)
Large 13N release in
active mode or
mechanical locked
compression.
Assure
correct
movement of
the
compression
module. If
needed
replace the
compression
module.
High priority
Alarm.
Compressions out
of range

Stryker LUCAS 3 Specifications

General

Device Type	Chest Compression System
Power Source	Rechargeable Lithium-ion Battery
Compression Depth	5.3 ± 0.2 cm (2.1 ± 0.1 in)
Battery Life	45 minutes of operation
Battery Charge Time	Approximately 4 hours
Operating Modes	Pause
Patient Size	Fits most adult patients
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	–20 to +60 °C (–4 to 140 °F)
IP Rating	IP43
Compression Rate	100 compressions per minute
