Stryker LUCAS 3 Service Manual

LUCAS
®
3 Chest Compression System – Service Manual
3328798-002, ©2017 Physio-Control, Inc.
Page 42 of 91
Error Codes from Control CPU
Error Code
Explanation
Probable Cause
Module to
check /
replace
User
Notification
LRG Text
T1_C_EE
No=0x10
Control EE-
Prom
CheckSum
data error
CPU fault
Replace
Control board
High priority
Alarm.
Internal fault -
contact Technical
Support
T1_C_RAM
No=0x11
Control Preset
CheckSum
data error
CPU fault or
communication faults
Use Service
Tool to set
default preset
or replace
Control board
High priority
Alarm.
Internal fault -
contact Technical
Support
T1_START_COM
No=0x13
No
Communication
between
Protective
and/or Battery-
Charger CPU's
at start
I2C communication
faults. Halted
Protective or Charger
CPU.
Check cable
between
boards.
Protective
board.
After 3 start
attempt,
High priority
Alarm.
Self-test fault
T1_PB_FLASH
No=0x14
Incompatible
programs in
Protective
board
Change of boards.
Reprogram
device.
High priority
Alarm.
Internal fault -
contact Technical
Support
T1_CAL_EE
No=0x15
Control
Potentiometer
Calibration
data
CheckSum
fault
Un-calibrated or
Too un-linear or
CPU EE fault
Perform a
new
calibration. If
un-linear fault
replace
compression
module. If
CPU EE fault
replace
Control board
Delayed
(10s) High
priority
Alarm.
Internal fault -
contact Technical
Support
T1_C_INITCURR
No=0x20
High Current
detected at
Start
Fault read current to
motor or broken driver
FET’s. +/- 12V supply
fault.
If needed
replace
Control board
After 3 start
attempt,
High priority
Alarm.
Self-test fault
T1_P_STATE_1
No=0x21
Start of
Release Test
time out (from
Protective)
Protective start
Error’s. I2C
communication faults.
Check for
Protective
Error’s. Cable
between
boards.
After 3 start
attempt,
High priority
Alarm.
Self-test fault
T1_C_RELEASE
No=0x22
Current
detected at
release/disable
test by Control
P45 module fault or in
cable between
boards.
Cable
between
boards.
Protective or
Control
board.
After 3 start
attempt,
High priority
Alarm.
Self-test fault
T1_P_STATE_3
No=0x23
Start of Current
Test time out
(from
Protective),
Current
detected by
Protective
Current detected by
Protective or I2C
communication faults.
Check for
Protective
Error’s.
Protective
board.
After 3 start
attempt,
High priority
Alarm.
Self-test fault
