Stryker LUCAS 3 Service Manual

LUCAS
®
3 Chest Compression System – Service Manual
3328798-002, ©2017 Physio-Control, Inc.
Page 54 of 91
Accessories
Catalog #
Description
Drawing #
Note
11576-000081
LUCAS CARRYING CASE, HARD SHELL
160200-00
11576-000094
LUCAS CARRYING CASE, HARD SHELL
VERSION 3.1
160200-01
11576-000080
LUCAS BATTERY, DARK GRAY
160201-00
21576-000074
LUCAS STABILIZATION STRAP
160203-00
11576-000050
LUCAS 2 PATIENT STRAP (PAIR)
300021-00
11576-000046
LUCAS 2 SUCTION CUP
100593-00
3-PACK
11576-000048
LUCAS 2 CAR CABLE
150206-00
12-28 V DC
11576-000083
LUCAS BATTERY CHARGER US
160207-00
11576-000084
LUCAS BATTERY CHARGER EU
160207-01
11576-000085
LUCAS BATTERY CHARGER GB
160207-02
11576-000086
LUCAS BATTERY CHARGER AU
160207-03
11576-000087
LUCAS BATTERY CHARGER JP
160207-04
11576-000088
LUCAS BACK PLATE, SLIM
160208-00
11576-000089
LUCAS BACK PLATE ANTI SLIP, SLIM BACK
160209-00
11576-000055
LUCAS 2 POWER SUPPLY US
150210-00
11576-000056
LUCAS 2 POWER SUPPLY EU
150210-01
11576-000057
LUCAS 2 POWER SUPPLY GB
150210-02
11576-000058
LUCAS 2 POWER SUPPLY JP
150210-03
11576-000059
LUCAS 2 POWER SUPPLY AU
150210-04
11576-000067
LUCAS 2 POWER SUPPLY SWZ
150210-05
11576-000071
LUCAS 2 POWER SUPPLY CANADA
150210-06
11576-000064
LUCAS PCI BACK PLATE
150211-00
(Radio
translucent)
11576-000091
LUCAS BUMPER INTEGRATED SHAFT SEAL,
BLACK, PAIR
160213-00
Tools
These tools are used for performing service and maintenance of LUCAS 3.
Standard Tools
1. Torx Screwdriver T10, T20, T25 (or set of Torx Keys)
2. Philips Screwdriver PH1
3. Small Flat Screwdriver
4. Flat Screwdriver 5.5x0.8 mm
5. Adjustable Torque Screwdriver with minimum range of 0.6-4.0 Nm
6. Bits Philips 1 (PH1)
7. Bits Flat 5.5x0.8 mm (5.5)
8. Bits Torx 10 (T10)
9. Bits Torx 20 (T20)
10. Bits Torx 25 (T25)
11. Hammer
12. Mandrel Cutting
13. Pliers Adjustable
14. Pliers ESD
15. Protection kit
16. Micro SD card reader
17. USB to USB mini Cable
18. Non-knurled flat nose plier
19. USB programming cable
20. REDEL extracting tool

Stryker LUCAS 3 Specifications

General

Device Type	Chest Compression System
Power Source	Rechargeable Lithium-ion Battery
Compression Depth	5.3 ± 0.2 cm (2.1 ± 0.1 in)
Battery Life	45 minutes of operation
Battery Charge Time	Approximately 4 hours
Operating Modes	Pause
Patient Size	Fits most adult patients
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	–20 to +60 °C (–4 to 140 °F)
IP Rating	IP43
Compression Rate	100 compressions per minute
