Stryker LUCAS 3 Service Manual

LUCAS
®
3 Chest Compression System – Service Manual
3328798-002, ©2017 Physio-Control, Inc.
Page 53 of 91
21576-000051
TORSION SPRING
240-9
QTY: 2, See Spring picture in How to Replace
Support Leg
21576-000053
SCREW K40X14
WN1452
10150120-35
QTY: 6, For one Support Leg Assembly
Used to attach two pieces of Support Leg
21576-000054
SCREW DELTA PT
40X22 WN5452 A2
10150461-00
QTY: 3, For one Support Leg Assembly
Used to attach two pieces of Support Leg.
These three screws are in the middle of the
Support Leg.
21576-000056
SCREW MRT M3X6
A2 ISO 7045
1015007161
QTY: 4, Used to attach Control and Protective
Board Assembly to the Compression Module
Assembly
21576-000057
SERRATED LOCK
WASHER M3 DIN
6798A
1015021803
QTY: 4, Used to attach Belt Cover to
Compression Module Assembly
21576-000058
SCREW MRT M4x12
A2 ISO 7045
1015007178
QTY: 4, Used to attach Motor with Belt Wheel
Assembly to Compression Module Assembly
21576-000059
SERRATED LOCK
WASHER M4 DIN
6798A
1015021804
QTY: 1, Used between one screw and the
Terminal
21576-000060
TERMINAL M4 AMP
181949
1067227820
QTY: 1, Used to attach Ground Cable from
Hood Assembly
21576-000061
SCREW MFX-H
M3x6 A2 DIN 965
724322040
QTY: 4, Used to attach Mesh and Threaded
Plate on air intake side.
21576-000062
SCREW MFS M3x40
A2 DIN 963
723123842
QTY: 4, Used to attach Mesh, Fan Washer,
Fan cable assembly and Threaded Plate.
21576-000063
SCREW MRX-H
M3x50 A2 DIN 7985
724124040
QTY: 4, Used to attach Hood Assembly
21576-000064
SCREW MFT M5x20
A2
1015007248
QTY: 8, Used to attach Compression Module
Assembly and Protective and Control board
assembly (see row with Thread Plate) to
Upper Part Assembly
21576-000065
SCREW MRT M3x12
A2 ISO 7045
1015007163
QTY: 2, Used for tightening the clamp on
Bellows
21501-002853
TYPE LABEL
100940-00
QTY: 1, LUCAS 3 Type Label, placed on the
leg
21576-000089
BRACKET, HOOD,
LUCAS
150420-00
QTY: 1, metal bracket for fixation HOOD
21576-000090
CARD, MEMORY,
SD
150421-00
QTY: 1, LUCAS SD Card for storing Log files,
positioned on the Control Board
21501-002855
LABEL, UDI
100952-00
QTY: 1, LUCAS 3 UDI Label, placed on the
opposite leg compared to the Type Label
21340-000846
SOFTWARE, LUCAS
3, 3.0
250039-00
21340-000852
SOFTWARE, LUCAS
3, 3.1
250041-00
