Stryker LUCAS 3 Service Manual

LUCAS
®
3 Chest Compression System – Service Manual
3328798-002, ©2017 Physio-Control, Inc.
Page 43 of 91
T1_C_LOWCURR
No=0x24
Too low
Current at
Current test
Motor not connected
or broken. HALL
sensor signal faults or
Internal voltages.
Motor, HALL
cable. Check
for internal
voltages
faults.
Control board
After 3 start
attempt,
High priority
Alarm.
Self-test fault
T1_P_DISABLE
No=0x25
Protective
Disable at
current test
P45 module fault or in
cable between
boards.
Cable
between
boards.
Protective or
Control
board.
After 3 start
attempt,
High priority
Alarm.
Self-test fault
T1_P_POT
No=0x27
Read
Protective POT
time out
I2C communication
faults. Halted
Protective CPU.
Cable
between
boards.
Protective
board.
After 3 start
attempt,
High priority
Alarm.
Self-test fault
T1_C_POT
No=0x28
Pot value
incorrect (Miss
match at start)
or not changed
at moving.
Control and Protective
POT value divergence
> 10mm at start. POT
fault or un- linear.
Reference voltage
faults.
Check POT
values and
POT cables.
Compression
module.
Check for
voltages
faults.
After 3 start
attempt,
High priority
Alarm.
Self-test fault
T1_P_STATE_5
No=0x29
No end of
Protective
Current Test
(time out)
Protective current
read fault. I2C
communication faults.
Check for
Protective
Error’s.
Protective
board.
After 3 start
attempt,
High priority
Alarm.
Self-test fault
T1_B_OFF
No=0x2A
No Battery
Charger T1 test
done (time out)
Charger CPU not
done T1 test correct
or I2C communication
faults.
Check for
Charger
Error’s.
Protective
board.
After 3 start
attempt,
High priority
Alarm.
Self-test fault
T1_C_DOWN
No=0x2D
Control not
moving down
before REW
test
Motor connections.
Protective stop by
disable line.
Motor. Check
for Protective
Error’s.
After 3 start
attempt,
High priority
Alarm.
Self-test fault
T1_P_REW
No=0x2E
Protective Time
out at Rew test
Motor connections.
Protective POT signal.
Locked compression
module.
Motor.
Protective
POT. Check
for Protective
Error’s.
After 3 start
attempt,
High priority
Alarm.
Self-test fault
T1_C_TOTOP
No=0x2F
Control Time
out at move to
top
Motor and HALL
connections.
Locked compression
module.
Motor.
Compression
module.
After 3 start
attempt,
High priority
Alarm.
Self-test fault
INT_C_TEMP
No=0x34
Too High
internal board
temp.
> 85°C
Fan disconnected or
jammed. Broken
Temp sensor or
internal reference
faults.
Fan. Control
PCB
High priority
Alarm.
Too high
temperature
INT_CODE
No=0x36
Access of vital
function Code
fault (10ms)
Halted or disturbed
Control CPU.
Control
board.
High priority
Alarm.
Internal fault -
contact Technical
Support

Stryker LUCAS 3 Specifications

General

Device Type	Chest Compression System
Power Source	Rechargeable Lithium-ion Battery
Compression Depth	5.3 ± 0.2 cm (2.1 ± 0.1 in)
Battery Life	45 minutes of operation
Battery Charge Time	Approximately 4 hours
Operating Modes	Pause
Patient Size	Fits most adult patients
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	–20 to +60 °C (–4 to 140 °F)
IP Rating	IP43
Compression Rate	100 compressions per minute
